• Model NO.：SR1020
• HS Code：9025800000

Measurable objectsIlluminance and temperature, illuminance difference, maximumand minimum illuminance and temperature, integratingilluminance and integrating time, and average integrating illuminance.Photoelectric elementSilicon diodeThermal  probeNTC thermistorIlluminance
measuring
rangeTotal measuring range:0~200, 000 Lux, Lux, into four ranges
×1   0~199. 9 Lux
×10  200~1999. 9Lux
×100  2000~19999. 9Lux
×1000  20000~200000LuxTemperature measuring range0~40°CIlluminance±3%rdg (below 10000 Lux);accuracy±4%rdg (above 10000 Lux)Temperature accuracy±1.0 °CUnits of ill-uminance and temp-eratureFour combinations of units are available.
Lux/°C
Lux/°F
FC/°C
FC/°FIllumination data storageAutomatic:Up to 1900 groups of data can be stored. LuxLAB is used to set the storage cycle and whether to start or stop storage.Manual:Up to 60 groups of data can be stored. Whether to store is determined manually.LCD display upd-ate frequencyTwice per secondOperating temper-ature/humidity0~40°C, 10~90%RHStorage temper-ature/humidity-20~50°C, 10~90%RHPower supplyTwo AAA batteriesBattery life10 hours (continuous operation with a USB connection)Auto shutdownYou can set an auto shutdown timer through LuxLAB.
