• Model NO.：TPZT-1000
• Trademark：TOP
• Origin：Zhejiang, China (Mainland)

Basic Info.

Model NO. TPZT-1000 Trademark TOP Origin Zhejiang, China (Mainland)

Product Description

Name: Plant Transpiration Rate Meter

Model: TPZT-1000






Product Characteristics

1. Multiple parameters tested: test air temperature, leaf temperature, air humidity, PAR etc at same time, and count the transpiration rate and Stomatal conductance accordingly.
2. Intelligent: Menu display and Cursor operation; test process and results displayed in real-time, with small size, light, portable and one-person operation.
3. Widely application: with different leaf chamber, the meter is able to be used in field crops, fruit and vegetables, hay etc which are in different shape.
4. Cost-efficiency: very competitive price and convenient maintenance.

Technical parameters

1.  Air temperature (TL):High accuracy digital temperature sensor from Swaziland, Range: 0-50ºC, Resolution: 0.1ºC, Error: ±0.2ºC

2. Leaf temperature (TC):Platinum, Range: 0-50ºC, Resolution: 0.1ºC, Error: ±0.2ºC

3. Air humidity (RH):High accuracy digital temperature sensor from Swaziland, Range: 0-100%, Resolution: 0.1%, Error: ≤±3%

4. PAR:Silicon photocell with Correction filter, Range: 0-2500µmolm m²/s, Accuracy: <5µmolm m²/s

5. Flux: glass rotameter

6. Size of leaf chamber: 55mm x 20mm. customized available

7. Work environment: Temperature: 20ºC~50ºC, Relative humidity: 0-100% (without condensation of moisture)

8. Power: DC7.4V Li-ion Battery, 7-9hours continuously working

9.Data storage: 2GB SD card

10.Display: 320×160 lattice

11.Size: 260×260×130mm

12.Weight:  3.25kg
