• Model NO.：CNY-1218D
• Trademark：TOP
• Origin：Zhejiang, China (Mainland)
• HS Code：9031809090
• Production Capacity：1000 Set,Sets Per Month

Basic Info.

Model NO. CNY-1218D Trademark TOP Origin Zhejiang, China (Mainland) HS Code 9031809090 Production Capacity 1000 Set/Sets Per Month

Product Description

Product Manual
 1. Detection function
Multi-functional pesticide residue detection integrated edible agricultural product certification printing function. It can quickly detect organic phosphorus, carbamates, pyrethroids, herbicides, fungicides, other pesticides, and other pesticides in vegetables, fruits, grains, and tea. Including detection of organophosphates, carbamates, pyrethroids, herbicides, fungicides, and other pesticides. Contains chlorpyrifos, carbofuran, acetamiprid, omethoate, carbendazim, chlorothalonil, parathion methyl, carbendazim, acetochlor, fenpropathrin, imidacloprid, abamectin, Organophosphorus, aldicarb, alachlor, sporocarp, thiabendazole, fipronil, hydrocarbons, bifenthrin, motion methyl, chlorpheniramide, pyrethroids, paclobutrazol, Chlorothalin, Benthiastrobin, Thiacloprid, Metalaxyl, Parathion, Phoxim, Triazophos, Triadimefon, Paraquat, 4-Chlorophenoxyacetic Acid, 6-Benzyl Adenine, Fenthion, fenthion, chlorpyrifos-methyl, fenthion, iprodione.

2. Data tracing function
Realize the rapid detection of agricultural product safety, the printing of test reports, the safety traceability of agricultural products, and the real-time upload of data to the cloud platform. The two-dimensional code of the certificate can be traced through mobile phone scanning, and the mobile terminal can temporarily implant agricultural products advertisements.

3. Detection module
Built-in multi-wavelength spectrum analysis module and immune colloidal gold detection module

4. Pesticide detection range
Display and operating system: 10.1-inch color touch capacitive screen, Android operating system.

5. Hardware requirements
4-core clocked at 1.6GHz, 2G memory, with large-capacity data storage function, built-in SD card expansion function, large-capacity storage of data.

6. Input and output function
Intelligent Chinese and English input, handwriting input function, sample name and intelligent simple spelling input function of the inspected unit. Built-in speaker with video learning function.

7. The scalability of the instrument
Open test items, can add and delete test items, expand to 120 items.

8. Detection channels
12 spectral detection channels and 3 colloidal gold detection channels.

9. Detection and display function:
Automatically display the concentration of the test item in the sample and judge whether it is qualified.

10. Data storage function
Large-capacity data storage test records, including sample name, sample production unit, test data, test results, and test date.

11. Printing function
Built-in embedded micro thermal printer, directly print the test report of each detection channel, and print the self-adhesive certificate.

12. Data processing function
The instrument has data reading, processing, exporting, and transmitting functions, and the test record can be imported into a U disk.

13. Remote management function
The instrument can be remotely managed, remote upgrade, remote control, remote fault diagnosis, and remote training.

14. Communication function
Built-in wireless WiFi and RJ45 network port for direct access to the Internet. Can expand 4G, 5G Internet communication functions, and GPS/AGPS positioning.

15. Data networking function
Real-time upload, sharing, and export of detection data. It does not need to be equipped with a computer and can be connected to a third-party monitoring platform.Technical Parameters
  Wavelength: 410nm/412nm
Transmittance accuracy: ±2.0%
Repeatability of transmittance: ≤0.2%
3-minute stability: ≤0.2%
Detection channels: 12
Colloidal gold detection modules: 3 (expandable range 5-10)
Communication interface: 2 USB
Wireless communication interface: Bluetooth, wifi, 3G/4G wireless Internet access
Power supply: 220V±10%
 Configuration

Serial number	Name	Specification	Quantity
1	Testing equipment	12 channels	1 set
2	Power Adapter	12V, 5A	1 piece
3	Glass cuvette	12×12mm	12
4	Micropipette	100μL	1 piece
5	Pipette	5ml	1 piece
6	Reagent bottle	500mL	1 piece
7	Extraction cup	40mL	12
8	Beaker	250mL	1 piece
9	Glass test tube	Ø15×100mm	20 pcs
10	Plastic washing bottle	500ml	1 piece
11	Test tube rack	16 holes	1 piece
12	Electronic balance	300g/0.1	1 set
13	Electronic timer	1-99 minutes	1 piece
14	scissors		1 piece
15	Cutter		1 piece
16	Manual		1 serving
17	Certificate printing paper	Stickers	2 rolls
18	Ordinary printing paper	Thermal	2 rolls
19	Detection reagent
20	Pesticide detection reagent	Organophosphorus carbamate pesticide detection	300 times
	Acetamiprid Test Card	Immune colloidal gold detection	10 times
	Chlorpyrifos test card	Immune colloidal gold detection	10 times
	Chlorothalonil Test Card	Immune colloidal gold detection	10 times
	Carroway test card	Immune colloidal gold detection	10 times
	Omethoate Test Card	Immune colloidal gold detection	10 times
21	High-speed certificate label printer		Optional
