• Model NO.：GT60N
• HS Code：9031809090
• Production Capacity：50 Piece,Pieces , Week

Basic Info.

Model NO. GT60N HS Code 9031809090 Production Capacity 50 Piece/Pieces / Week

Product Description

Digital Glossmeter / Vancometer (GT Series)
Portable Gloss meter GT60N



1.Introduction:



   The serial of GT glossmeters are designed and manufactured according to international standard ISO2813,ASTMD523,DIN67530 and China standard GB9754,GB9966,GB/T3891. The technical parameters up to JJG696-2002.

Applications:
1. Measurement of Paint and Dope surface gloss on Car, Electronic appliance and Musical
instrument industry.
2. Measurement of floor board, marble, granite and ceramic tile gloss on architecture, decoration
industry.
3. Measurement of printing ink and paper on Printing and Casing industry.
4. Measurement of the others need to be measured.
5. Hard drawn aluminum alloys
Features:
1. Small and light, real easy to be carried and used.
2. One 1.5 mignon alkaline Battery can be used for almost 60 hours and 10000 reading.
3. High stability
4. Long-term stable light source needs no replacing for ever.
5. Ouartz crystal standard board, no excursion.


Model	SADT GT60N
Application	Paint, coating, printing, ceramics,metal surfaces,plating layer
Measuring range	0-99.9Gs, 100-1999Gs
Readout error	±0.2 (0~99.9) ±0.2%(100~1999)
Stability	±0.5 (0~99.9) ±0.5%(100~1999)
Aperture	60°
Measurement spot	10 x 20mm
Window size	14 x 28mm
Statistics	10 data
Data interface	RS232/USB
Data software	My Gloss
Power	1.5V AAA
Dimension (mm)	83 x 46 x 30
Net weight (g)	100
Standards	ISO2813, ASTMD523, DIN-67530, ISO7668, GB9754
