• Model NO.：CA-3000
• Light：LED
• Dimension L*W*H(mm)：665*585*512
• Water Consumption：<0.5L,Hour
• Printer：Built-in Thermal Printer, External Printer
• Transport Package：1 PCS,Carton
• Specification：ISO,CE
• Trademark：OEM
• Origin：China
• HS Code：90278099
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. CA-3000 Light LED Dimension L*W*H(mm) 665*585*512 Water Consumption <0.5L/Hour Printer Built-in Thermal Printer, External Printer Transport Package 1 PCS/Carton Specification ISO/CE Trademark OEM Origin China HS Code 90278099 Production Capacity 5000PCS/Year

Product Description

Tech parameter:
Random access,smart and compact.

Clotting Chromogenic,Immunologic measuring methods.

User friendly touchscreen interface,simple & easy to operate.

High throughput  routine assays.

Labor saving ,simple programming and real walk-away system.

Reagent open system,close system on request.

Multi-language software(optional ).

System Function:

Througput:60 tests/hour for PT

          50 tests/hour for PT and APTT

Parameters:PT,APTT,TT,FIB,AT-W,PLG, D-Dimer,FDP,etc.

Measuring methods:

          Clothing:Scattered Light Detection method

          Immunologic:Turbidimetric method,575nm

          Chromogenic:Colorimetric method,405nm

Memory:100,000 test results and 10,000 reaction curves

Quality control:12 QC File*10 test items*30 curve    12 month

Calibration:6 points*10 items

Automatic,Random Access

STAT sample priority

Auto re-diluent/re-test

Barcode-reading support(optional)

Sample Tray:

Sample tray:27 positions,user-defined STAT

Incubation temperature:37+-0.5ºC

Reagent Tray:

Reagent cooling:<16ºC

Reagent tray:23 positions

Reaction Tray:

Cuvettes on board:72

Reaction temperature:37+-0.5ºC

Min reaction volume:150ul

Probe:

With probe pre-heating

Automatic washing both inside and outside.

With collision protection,liquid level detection and inventory checking.

Print Solution:

Built-in thermal printer,external printer optional

Meauring and optic system:

Light:LED

Power:AC 110/240V,50-60+-1Hz

Temperature:10ºC-30ºC,humidity<85%

Water consumption:<0.5L/hour

Dimension L*W*H(mm):665*585*512

Weight:50KG
