Cxc-06 Raw Fiber Testing Machine
Zhejiang Top Cloud-Agri Technology Co., Ltd.- Power：AC220V,50Hz, 2800W
- Water Supply：Water Pressure>1.5MPa Water Temperature<20
- Delivery Time：in 10 Days After Recieving The Payment
- Size：670×450×670mm
- Transport Package：Wooden Box, Meet Export Standard Requirements
- Specification：ISO9001
Base Info
- Model NO.：CXC-06
- Trademark：TOP
- Origin：China (Mainland)
- HS Code：9031809090
- Production Capacity：20 Unit,Units Per Week
Description
Product description
Raw Fiber Analyzer tests raw fiber content according to acid and alkali boiling methods.
It adopts accurate concentration acid and alkali to boil samples in a particular condition, then remove soluble substances by ether, deducts the number of minerals by high-temperature burning.
Technical parameter
Measuring object: Raw fiber content in various kinds of grain, feed, food and other agriculture and sideline products
Reproducibility error:
Raw fiber level < 10% absolute value erroe≤ 0.4%
Raw fiber level >10% absolute value error≤ 4%
Measuring time: About 100min (including acid 40min, alkali 40min, filter and wash 20 min)
Water supply: Water pressure >1.5MPa water temperature <20° C
| Measuring sample quantity | 6/times |
| Power | AC220V/501HZ, 2800W |
| Size | 670×450×670mm |
| Weight | 30kg |
