• Model NO.：SY-0719A
• Specification：SGS
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

Basic Info.

Model NO. SY-0719A Specification SGS Trademark SAMYON Origin Cn HS Code 903180 Production Capacity 100sets Per Month

Product Description

Summary
This instrument is designed and made as per industrial standard T0719-2011 Wheel Track Test for Bituminous Materials in JTG E20-2011 Standard Test Methods
of Bitumen and Bituminous Mixtures for Highway Engineering. It is used to determine the wheel track resistance property of bituminous mixtures under high
temperature condition(Immersed in water or not immersed in water).

I. Main technical features
1. PWM temperature control. It can control :(1)Water temperature in chamber during water immersed wheel track test
(2) Ambient temperature of constant temperature chamber at a time.
2. The constant temperature chamber adopts outside circulatory heating mode. The uniformity and stability is good. No overshoots.
3. It shows time- displacement curves and time- temperature curves during a test.
4. It equips an absolute temperature sensor. No temperature drift in a long time test.
5. The mechanical structure adopts wheel movement mode.
6. One wheel tester. It can determine both water immersion test or no water immersion test.

II. Main technical specifications
1.Sample size: 300mm×300mm×(30~200)mm (Grinding wheel molding)
300mm×15mm×50mm(Cutting on site)
2. Working mode: Rod drive
3. Rubber hardness: 78±2 at 60ºC,international standard.
4. Test wheel movement: 230mm±10mm
5. Grinding rate: (42±1)times/min (21 times of returns/min);
6. Loading device: (0.7MPa~1.3 MPa)±0.05Mpa when CPRESS is at 60ºC.
7. Displacement measuring range: 0mm~30mm
8. Displacement measuring accuracy: <0.01mm
9. Wheel track test time: 60 minutes~240 minutes. 60 minutes is standard.
10. Temperature controle for constant temperature chamber: Ambient temp.~80ºC,precision ±0.3ºC.
11. Deformation measurement: Precision 0.3%,minimum division 0.005mm.
12. Test temperature: 45ºC~85ºC, precision 0.5ºC
13. Working environment: Temperature 0ºC~50ºC,RH ≤90%
14. Drive motor power: 0.75kW,1450r/min;
15. Power supply: 3 phases and four lines. Power 3.5KW,The yellow line is working zero line
16. Dimension: 1510mm×740mm×146mm
17. Net weight: About 0.5 T
