Biobase HPLC 4 Channels High Performance Liquid Chromatography Psyche
Biobase Meihua Trading Co., Ltd.- Appliance：Medical Research
- Ray Type：UV,Vis
- Detector：UV,Vis Dector
- Certification：CE, ISO, IEC, GMP
- Stationary Phase：Liquid Solvent
- Mobile Phase：Liquid
Base Info
- Model NO.：BK-LCGH3100
- Chromatography Type：Liquid Chromatography
- Flow Rate Range：0.001ml,Min-10.000ml,Min
- Maximum Pressure：45MPa
- Pressure Accuracy：<3.0%
- Pressure Pulsation：<0.1MPa
- Wavelength Repeatability：<0.1nm
- Wavelength Range：190-700nm
- Band Width：8nm
- Response Time：0.0s-5s
- Baseline Noise：0.5*10-5au
- Gross Weight：68kg
- Path Length：10mm
- Light Source：Deuterium
- Degasser：for Model Bk-Lcql3100 Is Standard with It
- Transport Package：International Standard
- Specification：High Performance Liquid Chromatography
- Trademark：BIOBASE
- Origin：China
- Production Capacity：100 Units,Month
Description
Model
BK-LCI3100
BK-LCGH3100
BK-LCQL3100
High Pressure Constant Flow Pump
Quantity
1 Set
2 Set
1 Set
Flow Rate Range
0.001mL/min-10.000mL/min
Flow Accuracy
≤±0.2% (1.00ml/min, H2O,R.T.,8.5MPa)
Flow Precision
RSD≤0.075% (1.00ml/min, H2O,R.T.,8.5MPa)
Maximum Pressure
45MPa
Pressure accuracy
≤±3.0%
Pressure pulsation
≤0.1MPa
UV/VIS
Detector
Wavelength Range
190-700nm
Wavelength Repeatability
≤0.1nm
Wavelength Accuracy
≤±1.0nm
Band Width
8nm
Response Time
0.0s-5s
Baseline Noise
≤±0.5×10-5AU
Drift
≤1.0×10-4AU/h
Path length
10 mm(analytical cell)
Light Source
Deuterium Lamp
Low-Pressure Gradient Unit
Integrated vacuum degasser
/
/
4 channel
Composition Rang
0-100%
Composition Precision
≤0.2% RSD
Composition Accuracy
≤±2.0%
Data-processing Workstation
Internal and external standard calculation methods
Automatically displays, prints, exports and starts other programs after the completion of a measurement.
Comply with the requirements of the 21 CFR Part 11 directive of the FDA
3100 System Kits
1 Set
Power Supply
AC110/220V±10%, 50/60Hz
Optional Accessory
Column Oven, Autosampler, Degasser, Diode Array Detector, Refractive Index Detector, Evaporative Light Scattering Detector, Fluorescence Detector
Package Size(W*D*H)
600*440*380mm*4
Gross Weight
68kg
3. Features of High Performance Liquid Chromatography:
* Adopting mature and reliable mechanical structure, optical structure and circuit structure of core technology
* Stepper motor 64 subdivision control technology to improve accuracy at low flow rates
* Straight-through pressure transmitter
* Scientific air duct design to effectively reduce baseline drift
