Analysis Instrument

Portable Digital Roughness Tester Roughscan

Sino Age Development Technology
  • Delivery:Within 10 Workdays Upon Receipt of Full Payment
  • Transport Package:Carton
  • Specification:SGS
  • Trademark:SADT
  • Origin:China

Base Info

  • Model NO.:RoughScan
  • HS Code:9031809090
  • Production Capacity:50 Piece,Pieces , Week

Description

Basic Info.

Model NO. RoughScan HS Code 9031809090 Production Capacity 50 Piece/Pieces / Week

Product Description

Surface Roughness Tester RoughScan
Portable Digital RoughScan Surface Roughness Tester
Portable Digital Roughness Tester RoughScan

RoughScan is a portable, batterypowered, micro processed instrument for checking surface roughness with digital readout on LCD. RoughScan surface roughness tester can be widely used in laboratory, inspection area in the shop, or wherever on-suit surface roughness testing is required.
ModelRoughScan
Display3-digit LCD
Measuring rangeRa(ISO): 0.03μ m-6.3μ m/1μ " -250μ "
Rz(DIN): 0.2μ m-25.0μ m/8μ " -999μ "
Ry/Rmax(ISO): 0.2μ m~250μ m/8μ " ~999μ "
Resolution0.01μ m/1μ "
Accuracyconform ISO and DIN standards
Uncertainty≤ 2%
Cut-off(l )0.8mm/0.30" , ANSI 2RC Filter
Power9-volt alkaline battery
Battery capacityapprox. 3000 measurements
Probe typepiezo-electric
Maximum stylus force15.0mN / 1500mgf
Operating temperature10° C~45° C / 50° F~113° F
Storage temperature0° C~60° C / 32° F~147° F
