• Model NO.：AIC-11239
• Gas Supplies：Propane and Natural Gas
• Gas Flow Rate：0~1000 Ml,Min
• Blue Inner Flame：38mm
• Color：White
• Delivery Time：About 40 Days
• Test Object：Rigid Cellular Thermal Insulation Materials
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：30 Sets,Month

Basic Info.

Model NO. AIC-11239 Gas Supplies Propane and Natural Gas Gas Flow Rate 0~1000 Ml/Min Blue Inner Flame 38mm Color White Delivery Time About 40 Days Test Object Rigid Cellular Thermal Insulation Materials Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 30 Sets/Month

Product Description

Introduction

The foam horizontal burning characteristics tester is designed according to the national standard GB/T 8332-2008: the horizontal combustion method is used to determine the combustion performance of foam. It is suitable for measuring the horizontal combustion performance of small samples of foamed plastics with a density of less than 250kg/m³ under a small flame. The Horizontal Burning Characteristics Tester is equipped with PLC and touch screen to realize the intelligent measurement of the experiment, which can provide the experimenter with convenient and simple operation process to the greatest extent.



Standards

is.11239.12.METHODS OF TEST FOR RIGID CELLULAR THERMAL INSULATION MATERIALS - PART 12: HORIZONTAL BURNING CHARACTERISTICS

GB/T 8332-2008



Main Features

1. The Horizontal Burning Characteristics Tester is composed of a test part and a control part, and adopts an integrated design, which is convenient for on-site installation and debugging.

2. A large observation window is convenient for observing the burning state of the sample; the volume inside of box is not less than 0.5m³;

3. Horizontal Burning Characteristics Tester adopts advanced industrial appearance and control design, easy to reach the sample and burner;

4. The burner can be controlled to move after closing the door. Equipped with smoke exhaust holes and exhaust fans;

5. The Bunsen burner imported from the United States meets the requirements of ISO10093:1998. The length of the barrel is 100±10mm, and the inner diameter is 9.5±0.3mm. The height of the blue flame is precisely controlled to 25~35mm.Equipped with wing-top nozzles, the height is 400mm; the vertical combustion: the blowtorch is 15° with the lead line;

6. Programmable controller PLC+touch screen, realize control,detection,calculation,data display:

(1) Pulse high-voltage electronic automatic ignition;

(2) Time reminder, timing is automatically stored and reflected in the test report;

(3) Test time and heating time can be set on the touch screen;

(4) Intelligent display of temperature on LCD screen;

• Imported pressure gauge and pressure regulating valve.
• Imported needle valve cooperates with gas mass flow meter to accurately control gas flow.
• The automatic timer can record the test time;
• Flame height: horizontal combustion: the blue inner flame is 38mm, and the temperature measured from the top of the wing is 1000ºC;
• Sample holder: horizontal combustion: Φ0.8mm steel wire, each side of the mesh is 6.4mm long, the length of the mesh is 215mm, the width is 75mm, and the height is 13mm;



Using conditions:

1.Ambient temperature: 10~35ºC; relative humidity: ≤75%;

2.Power supply : AC 220V±10V, 50Hz;

3.Gas source: propane and natural gas with purity ≥95%;

4.Gas flow rate: 0~1000 ml/min adjustable;

5.Dimensions: 1200mm×600mm×900mm;

6.Weight: 25 Kg.

Factory overview

Customer Feedback

Germany

USA

Transporation

FAQ
1.What's the delivery time?
About 40 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
