Portable Vibration Tester EMT220, Vibration Measurer EMT220
Sino Age Development Technology- Delivery：Within 10 Workdays Upon Receipt of Full Payment
- Temperature：0~50degree
- Dimension：185mm×68mm×30mm
- Net Weight：200g
- Key Words：Portable Vibration Meter
- Transport Package：Carton
Base Info
- Model NO.：EMT220
- Specification：SGS
- Trademark：SADT
- Origin：China
- HS Code：9031100090
- Production Capacity：50 Piece,Pieces , Week
Description
Temperature measurement: ± 1% Measurement value; ± 1 Digit
Vibration Frequency Range:
10 ~ 1 kHz (Normal type)
5 ~ 1 kHz (Low frequency type)
1 ~ 15 kHz (only at "HI" position for acceleration)
Display: Digits liquid crystal display
Sample period: 1 second
Vibration measurement value readout:
Displacement: Peak to peak value (r. M. S. × 2√ 2)
Velocity: Root mean square (r. M. S. )
Acceleration: Peak value (r. M. S. X√ 2)
Readout-keeping function
Readout of vibration / temperature value can be remembered after
Releasing the Measure Key (Vibration / Temperature Switch)
Output Signal:
2V AC (peak value) (load resistance above 10 kΩ At full measuring scale)
Power supply:
6F22 9V laminated cell
Power on / off:
Battery life about 30 hours for continuous use
Power up when pressing Measure Key (Vibration / Temperature Switch)
Power automatically shut off after releasing the Measure Key for one minute
Operating condition:
Temperature: 0 ~ 50 centigrate
Humidity: ≤ 90% RH
Volume:
185 mm× 68 mm× 30 mm
Weight: 200g
