Colorimeter /Color Reader/ Color Meter Sc20
Sino Age Development Technology- Delivery：Within 3 Workdays Upon Receipt of Full Payment
- Accuracy：<0.2
- Test Range：L: 0~100, a: -128~127, B: -128~127
- Dimension (mm)：171X50X49
- Weight (G)：204
- Key Words：Colorimeter
Base Info
- Model NO.：SC20
- Transport Package：Carton
- Specification：SGS
- Trademark：SADT
- Origin：China
- HS Code：9031809090
- Production Capacity：50 Piece,Pieces , Week
Description
Basic Info.
Model NO. SC20 Transport Package Carton Specification SGS Trademark SADT Origin China HS Code 9031809090 Production Capacity 50 Piece/Pieces / WeekProduct Description
Colorimeter /color reader/ Color Meter SC20Precise Color Difference Meter SC20
Product Description
SC20 portable color difference meter ( color meter, colorimeter, color reader) is widely applied to quality control of plastic and printing industries. It makes you capture color efficiently and accurately.
Key Features
1. Easy operation makes you use it easily.
2. Widely applied to quality control of plastic and printing industries.
3. Display direc tly color difference by E*ab, L*a*b, CIE_L*a*b, CIE_L*c*h.
4. Standard deviation within E*ab0.2 (test condition: Choose average values by 12 PCS white tabula).
5. I t can be connec ted with computer to do the inspec tion by sof tware with USB expansion Interface.
Specifications
| Model | SC20 |
| Accuracy | < 0.2 Δ E*ab |
| Test range | L: 0~100, a: -128~127, b: -128~127 |
| Display | Δ E*ab, CIE_Lab, Δ Lab, CIE_Lch |
| Sensor | Silicon photodiode array |
| Aperture (mm) | Ø 8 |
| Light source | C light source |
| Test time | About 3 seconds |
| Test interval | 2 seconds |
| Power off | Automatically in 5 min |
| Working environment | 0~40oC, < 85%RH |
| Power supply | DC/5V (1.5A)/2 x 1.5V (AAA) battery |
| Net weight (g) | 204 |
| Dimension (mm) | 171x50x49 |
| Application | Measure any color of smooth surfaces |
