• Model NO.：AQMS-02
• Type：Laser Gas Analyzer
• Measuring Principledetection Principle：Electrochemistry (Honeywell, USA)
• Measuring Range：0-1, 0-10, 0-100 (Special Range Can Be Customized)
• Unit：Mg,M3
• Discrimination Rate：0.001,0.01,0.1,1
• Indication Error：≤±3% Fs
• Repeatability：≤±1%
• Zero Drift：≤ 1% (Fs,Year)
• Response Time：≤20 Seconds (T90)
• Dimensions：180mm*140mm*92mm
• Transport Package：Wooden Package
• Trademark：Scince
• Origin：Suzhou, China
• Production Capacity：50sets,Month

Basic Info.

Model NO. AQMS-02 Type Laser Gas Analyzer Measuring Principledetection Principle Electrochemistry (Honeywell, USA) Measuring Range 0-1, 0-10, 0-100 (Special Range Can Be Customized) Unit Mg/M3 Discrimination Rate 0.001/0.01/0.1/1 Indication Error ≤±3% Fs Repeatability ≤±1% Zero Drift ≤ 1% (Fs/Year) Response Time ≤20 Seconds (T90) Dimensions 180mm*140mm*92mm Transport Package Wooden Package Trademark Scince Origin Suzhou, China Production Capacity 50sets/Month

Product Description

Gas Alarm System for Detection of Flammable or Toxic Gas Leaks in Industrial EnvironmentsProduct Profile
 AQMS-02 Gas Alarm System adopts imported intelligent gas sensor with high sensitivity and precision. The product is used to detect the leakage of combustible or toxic gases in industrial environment. The whole detector adopts flameproof structure to ensure safety.




Advantages
Imported high-performance sensors have high measurement accuracy, good repeatability and long service life.
Adopt independent 16-bit AD chip and 4-layer circuit board design, which has stronger anti-interference ability.
The units of mg/m³, ppm, VOL and LEL can be selected.
The embedded 32-bit ultra-low power processor is adopted, and the response speed is fast.
Automatic protection against high concentration gas.
It has the function of restoring factory settings to prevent misoperation.
The instrument is equipped with infrared remote controller, which is easy and convenient to operate without opening the cover.
Three-wire 4-20mA, RS485 signal output optional, relay output.
The explosion-proof grade is Exd II CT6, certified by the national explosion-proof electrical inspection center.
Applications
Petroleum and petrochemical, metallurgy, environmental protection, gas, fire protection, municipal administration, chemical industry, shipping, electric power, process control, sewage treatment, emergency rescue monitoring and other industries.
Technical Parameters

Detection principle	Electrochemistry (Honeywell, USA)
Measuring range	0-1, 0-10, 0-100 (special range can be customized)
Unit	mg/m3
Discrimination rate	0.001,0.01,0.1,1
Sampling mode	Free diffusion type, online continuous detection
Indication error	≤±3% FS
Repeatability	≤±1%
zero drift	≤ 1% (fs/year)
Response time	≤20 seconds (T90), (higher requirement depends on sensor performance)
Power supply source	12-30V DC
Power	≤2.5 W(DC24V)
Ambient pressure	80kPa-120kPa
Ambient temperature	-20ºC-+60ºC (typical value), -40ºC-+80ºC (limit value)
Ambient humidity	10%-95%RH (without condensation)
Explosion proof sign	Ex d II CT6
Protection grades	IP66
Dimensions	180mm*140mm*92mm (height * width * thickness)
Weight	About 1.6Kg (aluminum alloy shell)

1. Are you a trading company or manufacturer?we are a professional tester manufacturer with 25 years of industry experience. Our factory is located in Suzhou, where is only 100 kilometers far away from Shanghai Hongqiao International Airport. It is pretty convenient for you to make a visit.
2. What is the L/T?
The lead time will be between15 and 30 days after deposit payment. If there is stock for the instrument you want, timely shipment will be arranged within 7 days.

3. What is your terms of payment?
Based on our sales policy, T/T 30% as deposit should be paid before order, and 70% balance payment should be completed before shipment. We will provide you with real photos or video of the instrument before balance payment.

4. What is your terms of delivery?
Available in EXW, FOB, CFR and CIF.

5. What is your packing for the tester?
Generally, packed with wooden case. We can do some adjustments in terms of your special requirement.

6. Can the mask tester be certified?
There is certification requirements for mask only, and there has no relevant certification requirements for mask tester, but a calibration report is required. we will provide a calibration report with a randomizer for our mask test instrument. The calibration report is valid for one year. After then, we can also support the corresponding calibration service for small fee.

7. Do you have after-sales service?
We can provide on-site installation and commissioning service for you, but you need to bear the travel expense of our engineer. The warranty period will be one year. Free replacement parts will be supplied during this period. Only accessories and corresponding shipping charges will be charged out of the warranty period.

8. Is there an English interface for your instrument?
Our instrument can be customized on the base of your demand. For example, both mask tester and filter material tester can be displayed in Chinese, English and Korean interfaces. The instruction manual is available in both Chinese and English.
