• Model NO.：TPGA
• Physical Analysis Type：Nir Reflection Technology
• Operating Mode：Touch Screen
• Heating Mode：Rapid Heating
• Off Mode：Manual
• Place of Origin：Zhejiang, China (Mainland)
• Brand Name：Top
• Model Number：Tpga-2000
• Power：AC 220V
• Spectral Range：680-1050nm
• Resolution：Superior to 7nm
• Transmission Measurement Method：29mm
• Detector：Silicon Diode Array
• Product Size：360mm×250mm×300mm
• Detecting Time：1-3mins
• Internet Applications：USB, RJ45
• Transport Package：in Carton
• Specification：ISO9001: 2015
• Trademark：TOP
• Origin：Zhejiang, China (Mainland)
• HS Code：9031809090
• Production Capacity：200 Sets, Week

Basic Info.

Model NO. TPGA Physical Analysis Type Nir Reflection Technology Operating Mode Touch Screen Heating Mode Rapid Heating Off Mode Manual Place of Origin Zhejiang, China (Mainland) Brand Name Top Model Number Tpga-2000 Power AC 220V Spectral Range 680-1050nm Resolution Superior to 7nm Transmission Measurement Method 29mm Detector Silicon Diode Array Product Size 360mm×250mm×300mm Detecting Time 1-3mins Internet Applications USB, RJ45 Transport Package in Carton Specification ISO9001: 2015 Trademark TOP Origin Zhejiang, China (Mainland) HS Code 9031809090 Production Capacity 200 Sets/ Week

Product Description

Product description

TPGA-2000 Near-infrared soybean analyzer is applicable for the efficient, fast, non-destructive, quantitative analysis of moisture, protein, fat of the soybean, to provide rapid detection methods for soybean quality identification. The instrument can be used in laboratories, workshops, fields, and other differences.

Technical parameter
 Spectral Range:680-1050nm Res: Superior to 7nm Transmission Measurement Method:29mm Detector: Silicon diode array Measurement Method: Transmission,measurement can detect up to 10 subsamples per time Product Size:360mm×250mm×300mm Functions
 1. Efficient & Fast: Detecting time 1-3mins, simultaneously measuring a variety of indicators of the sample, greatly shorten the detection time. 2. Scientific Precision: The equipment uses patented testing technology, automatic acquisition of 10 subsamples for analysis, combined with advanced priority algorithm, the detection accuracy, and stability are improved. 3. Flexible & Diversified::According to the particle size of the sample, choose suitable optical path modules that can be matched to achieve different sample testing. 4. No damage: No need for grinding, whole grain can be the detector. 5. Intelligent analysis: Equipped with special analysis software, Self-check, Model correction, Wavelength correction, Testing, Auto-generate Report, and other functions. 6. Intelligent control: Equipped intelligent monitoring software, Electric(Power) status display, Temperature, and Humidity monitoring. 7. Convenient Operation:8inch touch screen, Windows7 operation system. 8. Compatible Power Supply: Continuous outdoor operations. 9. Internet Applications: With USB type A, USB type B, RJ45 interfaces. Using for daily maintenance, model upgrade & update database.
