• Model NO.：DSC-600B
• HS Code：9027809900
• Production Capacity：500 Sets Per,Mouth

Basic Info.

Model NO. DSC-600B HS Code 9027809900 Production Capacity 500 Sets Per/Mouth

Product Description

Overview
Differential Scanning Calorimetry (DSC) is a classical thermal analysis method for the thermal effect of programmable temperature. It has widely used in research and development of various materials and chemistry field, process optimization, quality control and failure analysis. Using the DSC method, we can study the phase transition of inorganic materials, the melting of polymer materials, the crystallization process, the polymorphism of drugs, and the solidquid phase ratio of foods such as grease. In line with national standard GB/T2951.42-2008, GB/T15065-2009, GB/T17391-1998, GB/T19466.6-2009.


Technical characteristics
1. Industrial-grade wide-screen touch structure, display rich information, including setting temperature, sample temperature, oxygen flow, nitrogen flow, differential thermal signal, various switch states.
2. USB communication interface, strong versatility, reliable signal without interruption, support self-recovery connection function.
3. Compact furnace structure, and the rate of temperature rise and fall can be adjusted arbitrarily.
4. The installation process has been improved, and all adopted mechanical fixing methods to avoid the contamination of differential heat signal by colloid inside the furnace.
5. Dual temperature probe to ensure high repeatability of sample temperature measurement.
6. The digital gas mass flowmeter automatically switches the two-way air flow, and the switching speed is fast and the stabilization time is short.
7. Standard samples to facilitate the customer to correct the temperature coefficient.
8. Software adapts computer screens of different resolutions; support notebook, desktop, WIN2000, XP, WIN7, WIN8, WIN10 and other operating systems.
9. Support user self-programming program to realize full automatic measurement steps. The software provides dozens of instructions, and the user can flexibly combine the instructions according to their own measurement steps and save them. Complex operations are simplified into one-button operation.
10. Optional refrigeration module (suitable for materials with low glass transition temperature and melting point temperature, or rapid cooling requirements).

Technical parameter
1.DSC range: 0 ~ ± 500mW
2.Temperature range: room temperature ~ 500 ° C
3. Heating rate: 0.1~80°C/min
4.Temperature resolution: 0.01 ° C
5.Temperature accuracy: ± 0.1 ° C
6.Temperature repeatability: ± 0.1 ° C
7.DSC accuracy: ± 2%
8.DSC resolution ratio: 0.001mW
9.DSC resolution: 0.001mW
10.Temperature control mode: heating, constant, cooling, cycle temperature control (full automatic control)
11.Curve scan: heating scanning
12.Atmosphere control: gas mass flowmeter automatically switches two gas channels
13.Display mode: 24bit color, 7 inch LED touch screen display
14.Data interface: USB standard interface, supporting the corresponding operating software
15.Parameter standard: equipped with standard calibrator with one-button calibration function, users can calibrate the temperature by themselves
16.Working power: AC220V 50Hz/60Hz

Has been actually applied to:
Measure physical and chemical changes related to heat, such as glass transition temperature and melting point,Melting temperature, crystallization and crystallization heat, phase transition heat, thermal stability, solidification/crosslinking, oxidation induction period, reaction kinetics, specific heat etc.



FAQ
What is the mini order quantity?
MOQ: generally 1 unit/piece/set

What payment methods are supported?
Payment method: By T/T, L/C, Alibaba Trade Assurance etc.
Payment terms: Generally, T/T 40% advanced, the balance paid by T/T when the machine is ready; or 100% irrevocable L/C at sight.

What are the available delivery methods?
Our port location: Chongqing, Shanghai or other main port of China
Delivering to: Worldwide
Delivering method: by sea, by air, by truck, by express, combined transportation

How long is the product date of delivery probably?
Delivery date differs with product type, order quantity, special requirement etc. Usually our big machine delivery date is around 10 ~ 20 days; test equipment or analyzer delivery date is around 5~10 days. Some products have stock, contact us anytime to get more information.

How long is the warranty period?
We warrants the plant supplied under agreed specification against defects in material and workmanship under normal use and service for a period of 2 years after start up of the system.

How is the technical services on the product?
Engineer available to service machinery overseas. If you have any technical question, you are welcome to contact us any time. We will response promptly and answer to your satisfaction. If required and necessary, we can send our engineer to your place to provide technical support.



Located at Chongqing city--a southwest electromechanical manufacturing center as well as national municipality, Chongqing TOP is a professional leading manufacturer and supplier of oil purifiers and various related testers. We consists of departments respectively for technological development, machinery manufacture, instrument manufacture, quality control etc. On basis of mature development and manufacture technology and highly qualified production management team, the products own high quality, easy operation, excellent performance and lone service life.

TOP Oil Purifiers are widespread in the fields of electric power, petrifaction, mineral, shipbuilding, steel construction, bridge, automobile and railway, playing a great role in reducing energy consumption for clients as well as environmental pollution. We provides you with reliable oil purifiers such as transformer oil purifier, turbine oil purification machine, hydraulic oil purifier, lubricating oil filtration machine, fuel oil restoration, oil and water separator, oil regeneration equipment, waste oil recycling equipment etc.

TOP Testers works on the development, production, market, technical and after-sale service for petrochemical analyzers, transformer substation electrical testing equipment and circuit detecting equipment. Main products are water content testers, surface/interfacial tension testers, flash point testers, kinematic viscosity testers, oil acidity testers, insulation oil dielectric strength testers, transformer characteristics testers, relay protection testers, high voltage testing equipment etc.
