• Model NO.：BMD-1
• Performance：Automatic
• Power Supply：220V
• Weight：0-50kg
• Certification：CE
• Customized：Non-Customized
• Model：Bmd-1
• Cavity：48L Resonant Cavity
• Teflon Coating：10 Layers
• Digestion Method：50 Preinstalled Methods
• Max. Temp.：305
• Temp. Accuracy：1
• Pressure Accuracy：0.01MPa
• Temperature Sensor：Optical Fiber Sensor
• Transport Package：Export Packing
• Specification：BMD-1
• Trademark：BIOBASE
• Origin：China
• Production Capacity：500 PCS , Mout

Model

BMD-1

BMD-2

Cavity

48L Resonant Cavity

Teflon Coating

10 layers

8 layers

Digestion Method

50 preinstalled methods,

programmable 100 methods

20 preinstalled methods,

programmable 50 methods

Max. Temp.

305ºC

Temp. Accuracy

±1ºC

Pressure Accuracy

±0.01Mpa

Temperature Sensor

Optical Fiber Sensor

Vessel Pressure Capacity

80 Mpa

75 Mpa

Vessel Quantity

12 Vessels

Vessel Volume

100ml

Microwave Cavity Material

SS316 with 10 layers Telflon

SS316 with 8 layers Telflon

Cooling Method

Forced air cooling

Interface

USB, RS232

/

Power Consumption

1600W

Power Supply

AC220±10%, 50Hz

External Size(W*D*H)

520*593*660mm

Package Size(W*D*H)

830*900*970mm

Gross Weight

107kg
