• Model NO.：DOG-2082S
• Transport Package：PP Bag, Carton
• Specification：SGS
• Trademark：Boqu
• Origin：Shanghai
• HS Code：9027809900
• Production Capacity：60000PCS,Year

Basic Info.

Model NO. DOG-2082S Transport Package PP Bag, Carton Specification SGS Trademark Boqu Origin Shanghai HS Code 9027809900 Production Capacity 60000PCS/Year

Product Description

DOG-3082YA Industrial Online Optical  Dissolved Oxygen Meter


DOG-3082YA on-line fluorescent dissolved oxygen analyzer is our company's new generation of all Chinese microcomputer based high-grade instrument, the principle of fluorescence method, maintenance free, no electrolyte solution added, no anode, cathode cleaning or replacement, no measurement drift.
DOG-3082YA has the characteristics of full Chinese display, Chinese menu operation, full intelligence, multi function, high measuring performance, environmental adaptability and so on. Can be widely used in sewage treatment plants, water plants and other industries of the liquid oxygen content measurement of special equipment.





Technical Indexes

1,Measuring range:(0~20.00)mg/L,(-10~55.0)ºC,adopt Optical DO Sensor; 2,Resolution:0.01mg/L; 3,Repeat-ability:±2%.; 4,Current isolated output: 4~20 mA(load<750Ω ); 6,Output current error:≤±1%FS; 7,Alarm relay:AC220V,7A; 8,RS485communication interface(optional); 9,Power supply:AC220V±22V ,50Hz±1Hz;    DC24±2.4V,1A (optional); 10,Protection grade:IP65; 11,Clock accuracy: ± 1minute/month; 12,Data storage: 1 month(1unit/5minutes); 13,Data continuous saving time for power down:10years; 14,Dimension:146(L)×146(W)×108(D)mm;     Opening dimension:138×138 mm; 15,Weight: 0.8kg ; 16,Working condition:Ambient temperature: 0~60ºC   Relative humidity: <85%; 17,Sensor installation method: the distribution or the type of the sensor, please specify when the order is not specified by the sinking type

Packing & Delivery
Company Show
Abroad Exhibition
Customer Show
Application
Certification
FAQ1. Who are we?BOQU instrument focus on R&D and production of Water Quality analyzer&sensor since 2007. Our mission is To be brightest eye for water quality monitoring on earth.★ Employees: 200+ people
★ Annual growth rate: 35%
★ R&D experiences: 20+ years
★ Technical patents: 50+
★ Annual production quantities: 150,000pcs
★ Cooperation companies:  Boehringer Ingelheim, CM, Roche
★ Main Industries: Power plant, Water treatment plant, Drinking water, Pharmaceutical, Fish farming, Swimming pool.

2. How can we guarantee quality?

1) 100% OQC for all of products before shipping
Testing pictures and videos to be provided before shipping

3. What's our main business?
Whole solution for water quality instruments. Including analyzers and sensors for pH, COD, BOD,
conductivity, Dissolved Oxygen, Turbidity, TSS, Residual chlorine, Ammonia, Nitrate, Hardness and etc..

4. Why choose us instead of other suppliers?
1) Manufacturer was established since 2007, top supplier of water quality instrument.
One stop solution provider for water quality monitoring, thousands of projects reference.
24 hours after-sales service team, products training on time.
20+ years R&D experience, support OEM & ODM service.
50+ Patents for water quality analyzer and sensor

5. What service can we provide?
Incoterms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU,
Express Delivery, DAF, DES;
Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY,CHF;
Payment method: T/T, MoneyGram, Credit Card, PayPal,Western Union, Cash, Escrow;
Language: English, Chinese, Spanish, Korean
