Ds2 Series Full Wave Acoustic Emission Signal Analyzer
Beijing Samyon Instruments Co., Ltd.- Channels：2, 4, 6, 8 Channel
- Interface Type：USB2.0
- Operating System：Windows XP, Win7(32bit)
- Data Pass Rate：Over 48MB,S
- a/D Sampling Accuracy：16bit
- Waveform Acquisition Mode：Multi-Channel Simultaneous Sampling
Base Info
- Model NO.：DS2-A Series, DS2-B Series
- Input Voltage of Signal：±10V
- System Noise Level：±0.308mv
- Channel Input Impedance：50Ω
- Transport Package：Carton Case
- Trademark：SAMYON
- Origin：Cn
- HS Code：903180
- Production Capacity：600
Description
Type
DS2-A Series,DS2-B Series
Channels
2,4,6,8 channel
Interface type
USB2.0
Operating system
Windows XP,win7(32bit)
Data pass rate
Over 48MB/S
Waveform data storage mode
Continuous lossless waveform data storage
collecting through all channels simultaneously
Continuous collecting duration
5.8 hours(using 1TB harddisk) continuous lossless waveform data storage collecting through all 8 channels simultaneously by 3MHz sample rate
A/D sampling accuracy
16bit
Sampling rate
2-channels:10 MHz
4-channels:5 MHz,6 MHz
8-channels:2.5 MHz,3 MHz,1MHz,500 KHz,200 KHz,100 KHz
Waveform acquisition mode
Multi-channel simultaneous sampling
Input voltage of signal
±10V
System noise level
±0.308mV
Channel input impedance
50Ω
A/D converter nonlinearity
±0.5LSB
Signal input type
Single-ended signal
Trigger mode
Software trigger,the signal threshold trigger,external trigger
External parameter channel
8 channels (without DS2-A)
External parameter sampling accuracy
16bit (without DS2-A)
External parameter input voltage of signal
±5V/±10V (without DS2-A)
Operating temperature range
10ºC~50ºC
Power mode
AC 220
