• Model NO.：GDP-8000CM
• Mirror surface temperature sensor：PRT-100
• Single sample measurement time：90 seconds (stable)
• Operation temperature：-20 ~ +60 centigrade
• Measurement range：-90 ~ +20 centigrade
• Delivery time：1 month
• Dimension：470mm*200mm*400mm
• Accuracy：Better than 0.2ºC
• Transport Package：Standard Export Wooden Box
• Specification：470*200*400mm
• Trademark：HVHIPOT
• Origin：China
• HS Code：9031809090
• Production Capacity：2000 Sets,Year

Measurement methodAuto chilled mirror measurement (Stryn refrigeration principle)Mirror surface temperature sensorPRT-100Single sample measurement time90 seconds (stable)Operation temperature-20ºC ~ +60ºCMeasurement range-90ºC ~ +20ºCAccuracybetter than 0.2ºCResolution0.1ºCRepeatability±0.05ºC dew/frost pointDisplay unitºC, ppm (with a dew point conversion value of 20ºC in the environment)Gas flow400-600mL/minFlow displayImported digital flow meterSample gas pressure≤1MPaEnvironmental humidity90%RHPower supply220VAC ±10%, DC of Li battery (more than 6 hours battery life)Dimension470*200*400mm
