• Function：Storage
• Weight：0-100Kg
• Power Source：AC110V±10V
• Customized：Customized
• Transport Package：Movel
• Trademark：movel
• Origin：Shanghai
• HS Code：9011809090

Specification

Standard

Eliminating endotoxin

Low TOC

Comprehensive

Model

Ultra pure

Ultra pure UF

Ultra pure UV

Ultra pure UVF

Ultra pure plus

Ultra pure plus UF

Ultra pure plus UV

Ultra pure plus UVF

Flow procedure

PF+AC+RO+DI+TF

PF+AC+RO+DI+UF+TF

PF+AC+RO+UV+DI+TF

PF+AC+RO+UV+DI+UF+TF

Application

Microanalysis Environmental analysis

AA,ICP,IC

Buffer disposing

Pharmacy research

Medicine examining,

Molecular biology

PCR, gene research

Pharmacy research

Medicine examining,

Cell cultivating

IVF etc.

Micro organic analysis

Environmental analysis

HPLC,TOC

VOC,GC/MS

Pharmacy research

Medicine examining,

Molecular biology

Micro organic analysis

Environmental analysis

Pharmacy research

Medicine examining

Cell cultivating, IVF etc.

Feed water requirement

Tap water: TDS<200ppm,5-45ºC,1.0-4.0Kgf/cm²

(if inlet TDS>200ppm, extra pretreatment is recommended)

Purification system

Pretreatment unit

Special spun fiber filter ("plus UF/UV/UVF" model: outside 10" spun fiber filter)×1+Special active carbon block filter×1+Special active carbon block filter×1

RO unit

100GPD RO membrane×1 ("plus" model:2×100GPD RO membrane)

Subsequent unit

Ultrapure polishing resin cartridge× 4+(0.45+0.1)μm terminal filer×1

UV model:+Double wavelength(185&254)nm UV lamp cartridge×1

UF model:+5000 Doulton UF cartridge×1

UVF model:+Double wavelength(185&254)nm UV lamp cartridge×1+5000 Doulton UF cartridge×1

Ultrapure water quality

Resistivity

18.2MΩ.cm@25ºC

Heavy metal ions

<0.1ppb

TOC

<10 ppb

<5 ppb

Endotoxin

-

<0.001EU/ml

-

<0.001EU/ml

particle(>0.22μm)

<1/ml

Bacteria

< 1cfu/ml

RO water quality

< TDS(ppm, mg/l) of tap water×5%

Output(25ºC)

15 liters/hour* ("plus" model:30 liters/hour*)

Flow rate

2 liters/min(with pressure tank)(Less output with UF/UV cartridge)

Pure water outlet

RO water ,ultrapure water

Control system

Automatic electronic pressure sensor controlling, RO membrane auto flushing, automatic stop without water, automatic stop when water tank full, automatic cutting off water when pump stopping, guaranteeing 24 hours' work.

Water quality monitor

TDS test pen+ on-line resistivity monitor

Electric requirements

AC110-220V,50/60Hz, 48W/plus model:72W

Dimension and weight

Length×Width×Height:41×22×42cm / 12-14 kg

Standard configuration

Main body(including:1 set cartridge)+4.0 gallon water tank + TDS pen + accessory box

n  Feed water :TDS=200ppm, 25ºC, 50psi and 15% recovery rate.

n  GPD=gallon per day, 1gallon=3.78L.

n  The quality of feed water will influence outlet water quality and cartridge's life.

n  PF: Pretreatment, AC: Active carbon, RO: Reverse osmosis, DI: Deionization, UV: UV lamp (Double wavelength:254&185nm) UF: Ultra-filtration, TF: Terminal filter
