• Model NO.：HP-BGEL2000A
• Weight：0-100Kg
• Power Source：110V~240V ,50Hz
• Customized：Non-Customized
• Calculation Parameters：pH(Tc) Pco2(Tc) Po2(Tc) Hco3- Sbc Be Beecf Tco2 So
• Test Items：Pco2, Po2, pH
• Sample：Whole Blood 150UL
• Testing Time：50s
• Display Screen：8" TFT Colorful LCD Touch Screen
• Interfaces：RS232 ,Barcode Scanner
• Relative Humidity：110V~240V ,50Hz
• Printer：Build-in Thermal Printer
• Test Method：Automatic Sampling
• Specification1：Blood Gas Electrolyte Analyzer
• Transport Package：Standarf Pagkage
• Specification：SFDA, CMC, CMD, CE
• Trademark：HEPOBIO
• Origin：China
• Production Capacity：3000pics,Month

 SpecificationBlood Gas  Analyzer
 HP-BGEL2000A
 Test ItemsPCO2, PO2, pH, Na+,K+,CL-,Ca2+ .
 Calculation parameterspH(TC),PCO2(TC),PO2(TC),HCO3-,SBC,BE,BEecf,TCO2,sO2%,P50,A-aDO2,RI,Tca,nCa
 Measurement rangeItem
 Value
 Test ItemspH valuepH6.800~8.000
 Carbon dioxide pressurePCO28.0~200.0mmHg
 oxygen partial pressurePO20~800.0mmHg
 Calculation parametersHydrogen carbonate rootHCO3-22.0~26.0mmol/L
 Standard bicarbonateSBC22.0~26.0mmol/L
 Whole blood alkali superBE-2.0~2.0mmol/L
 Extracellular fluidBeecf-2.0~2.0mmol/L
 Of All Co2 EmissionsTCO223.0~27.0mmol/L
 Oxy hemoglobin saturationSO2%93.0~99.0%
 Half a saturation oxygenP5025.5~28.5mmHg
 The alveolar arterialA-aDO25~50mmHg
 RSBIRI<0.15
 STCaTca0.5~10.0mmol/L
 Standard calciumnCa0.3~5.0mmol/L
 Samplewhole blood 150μl
 Test Methodautomatic sampling
 Testing time50s
 Printerbuild-in thermal printer
 Display screen8" TFT colorful LCD touch screen
 Storage>=5000
 InterfacesRS232 ,Barcode scanner
 Temperature+15ºC -- +30ºC
 Relative humidity110V~240V ,50HZ





 blood gas analyserpH value6.800~8.000PH
 carbon dioxide pressure8.0~200.0mmHgPCO2
 oxygen partial pressure0~800.0mmHgPO2
 ionometric methodNa+50~200mmol/LNa+
 K+1.5~10mmol/LK+
 Cl-50~200mmol/LCl-
 Ca2+0.5~5.0mmol/LCa2+
 parameterHydrogen carbonate root concentration22.0~26.0mmol/LHCO3-
 standard bicarbonate22.0~26.0mmol/LSBC
 Whole blood alkali super-2.0~2.0mmol/LBE
 Extracellular fluid alkali super-2.0~2.0mmol/LBeecf
 Of All Co2 Emissions23.0~27.0mmol/LTCO2
 oxyhemoglobin saturation93..0~99.0%SO2%
 Half a saturation oxygen partial pressure25.5~28.5mmHgP50
 The alveolar arterial oxygen pressure difference5~50mmHgA-aDO2
 RSBI<0.15RI
 STCa0.5~10.0mmol/LTca
 Standard calcium0.3~5.0mmol/LnCa
