Dark-Colored Sample LCD Digital Automatic Polarimeter
Biobase Meihua Trading Co., Ltd.- After-sales Service：Online
- Warranty：One Year
- Display：Digital
- Appliance：Food Analysis, Medical Research
- Portable：Non Portable
- Certification：CE, ISO9001
Base Info
- Model NO.：BK-P2S,BK-P2B
- Type：Concentration Meter
- Light Source：LED Lamp
- Measuring Range：45°(Optical Rotation)120° Z(Sugar)
- Wavelength：589nm
- Readable Accuracy：0.001°(Optical Rotation)0.01°z(Sugar)
- Repeatability：0.002° (Optical Rotation)
- Test：Optical Rotation, Sugar Degree
- Transport Package：Cartoon,Wooden
- Specification：570*350*280mm
- Trademark：BIOBASE
- Origin：China
- HS Code：900290909
- Production Capacity：10000,Year
Description
Model
BK-P2S
BK-P2B
Light Source
LED lamp
Measuring Range
±45°(optical rotation) /±120° Z(sugar)
±45°(optical rotation)
Wavelength
589nm
Readable Accuracy
0.001°(optical rotation)0.01°Z(sugar)
0.002°(optical rotation)
MeasuringAccuracy
±(0.01+measurement value*0.05%)°(optical rotation)
±(0.03+measurement value*0.05%)°Z(sugar)
±(0.01+measurement value*0.05%)°
Repeatability
≤0.002° (optical rotation)
≤0.01° (optical rotation)
Test Mode
Optical rotation,sugar degree
Optical rotation
Test Tube
200mm,100mm
Sample Transmittance
>1%
>10%
Interface
RS232
Power Supply
AC 110V/220V±10%, 50/60HZ
External Size(W*D*H)
570*350*280mm
Package Size(W*D*H)
730*480*470mm
Gross Weight
36kg
