• Model NO.：AT7200
• Display：1.44-Inch LCD
• Consecutive Working：Around 2000 Times
• Dimension：293mm*413mm*407mm(L*W*H)
• Weight：600g
• Model：At7200
• Transport Package：Gift Box
• Specification：410mm X 52mm X 52mm @330g
• Trademark：Airradio
• Origin：China
• Production Capacity：50000piece,Year

Basic Info.

Model NO. AT7200 Display 1.44-Inch LCD Consecutive Working Around 2000 Times Dimension 293mm*413mm*407mm(L*W*H) Weight 600g Model At7200 Transport Package Gift Box Specification 410mm X 52mm X 52mm @330g Trademark Airradio Origin China Production Capacity 50000piece/Year

Product Description

Product Description

Duel functions alcohol tester---pump suction and accurate test, AT7200 adopt fuel-cell sensor and semi-conductor as its core component that can inspect accurately concentration of the breath alcohol.

Main Features

 32-bit MCUFuel Cell sensorActive and Passive TestLCD Color 128 x 128 Matrix DisplayTest Result Uploading to Server via GPRS(Optional)Test Result Printed and Uploading to ComputerTraffic Baton with White and Red Lighting Indication GPS physical localization(Optional)Real Time and Temperature Indication Under Voltage Remind Choice of Units-mg/l, mg/100ml, %BAC, ‰BAC, g/lFast Warming Up, Response and RecoveryNo Mouthpiece Needed-Environmental and Hygiene Friendly

Both fuel cell and semiconductor sensor-accuracy and fast

Both accurate and rapid pump suction test method

3.7V/5000 mAh Lithium battery

Traffic baton with white and red indication

Switchable result units(mg/l, g/l, %BAC, ‰BAC)and temperature scale(ºC, ºF)

Anti-backflow mouthpiece for health and safety

Application Scenarios

Police station, traffic management, factory, workshop, office, car, hotel, mine, etc.

Main Specifications

Model	AT7200
Sensor	Accurate Testing: Fuel Cell
	Pump Suction: Semiconductor
Sensor Life	Fuel Cell: 2 Years
	Semiconductor: 5 years
Range	Pump Suction Mode: 0~220mg/100ml(0~1.000mg/L)
	Accurate Testing Mode: 0~440mg/100ml(0~2.000mg/L)
Consecutive Working	Around 2000 times
Dimension	293mm*413mm*407mm(L*W*H)
Weight	600g



Company Profile
Henan Weiguo Intelligent Technology Co., LTD., founded in 2015, is an important subsidiary of Hanwei Electronics Group Corporation (Stock no.:300007) in the field of intelligent healthy, safe home and IoT business. Henan Weiguo Intelligent Technology Co., LTD., relying on the core sensor technology, focuses on gas and smoke alarm, air quality monitor, alcohol tester and firefighting products. Based on introduction of featured technology from both Hanwei Electronics Group Corporation and abroad, Henan Weiguo intelligent Technology Co., LTD., has developed into an innovative company with the collection of design, R&D development, production, sales and service. We will always be committed to becoming the leader in intelligent hardware, providing safe, healthy, environmentally friendly and intelligent working and living environment for families and users all over the world.
