• Model NO.：ABH210
• Gas：Combustible Gas ,Toxic Gas
• Type：Infrared Absorption Analyzer
• Name：Fixed Gas Detector
• Display：LCD
• Voltage：DC 12-28V , 500mA
• Power Consumption：Power Ripple Is Less Than 20mv
• Ex Grade：II 2g Ex dB Iic T6 GB
• Ingress Protection：IP66
• Output：4-20mA Output RS485
• Transport Package：Carton
• Specification：198*140*77
• Origin：China
• Production Capacity：5000000piece,Year

Gas typerangeLow alarm pointHigh alarm pointResolutionEX0-100% LEL20% LEL50% LEL1/0.1% LELH2S0-100ppm10ppm35ppm1/0.1ppmCO0-1000ppm50ppm150ppm1/0.1ppmO20-30% VOL19.5% VOL23.5% VOL0.1% VOLPlease contact the company for other gas combinationsAccuracy:≤±5% F.S.Response time≤60 SIndication mode:high definition LCD screenWorking environment:Temperature -20ºC~+50ºC; humidity <95%RH condensationWorking voltage:DC 12V-28V 500mAoutput 4-20mA /  RS485Protection level:Ip66shell material:Die-cast aluminum, explosion-proof and anti-corrosionWeight:less than 1.6kgStandby time:continuously 8 hours working after full chargeEx grade:II 2G Ex db IIC T6 GbGB15322.1-2019 (The first part of combustible gas detection alarm: measuring range of 0-100% LEL point type combustible gas detector)
4.Company Profile

Henan Weiguo Intelligent Technology Co., LTD., founded in 2015, is an important subsidiary of Hanwei Electronics Group Corporation (Stock no.:300007) in the field of intelligent healthy, safe home and IoT business. Henan Weiguo Intelligent Technology Co., LTD., relying on the core sensor technology, focuses on gas and smoke alarm, air quality monitor, alcohol tester and firefighting products. Based on introduction of featured technology from both Hanwei Electronics Group Corporation and abroad, Henan Weiguo intelligent Technology Co., LTD., has developed into an innovative company with the collection of design, R&D development, production, sales and service. We will always be committed to becoming the leader in intelligent hardware, providing safe, healthy, environmentally friendly and intelligent working and living environment for families and users all over the world.
