SA1000 Series Frequency Characteristic Analyzer for School and Lab Use

Shijiazhuang Suin Instruments Co., Ltd.
  • Warranty：18 Months
  • OEM/ODM：Yes
  • Sweep Range：20Hz~140MHz
  • Sweep Mode：Linear, Log or Tone
  • Transport Package：Carton Package
  • Specification：363*154*327 mm

Base Info

  • Model NO.：SA1030C,D SA1050C,D SA1080C,D SA1140C,D
  • Trademark：SUIN
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：30, 000 Sets,Year

Description

SA1000C:amplitude-frequency,phase-frequency,frequency discrimination and SParameters can be measured
SA1000D:amplitude-frequency,phase-frequency and frequency discrimination can be measuredSweep ModeLinear,Log or ToneOutput Amplitude>0.5VrmsInput Impedance50Ω/High ImpedanceOutput Impedance50ΩOutput Attenuation0~80dB,1dB stepInput Gain10~-30dB,10dB stepPhase Range-180°~+180°Phase Resolution1°Amplitude range of input0.1V≤A≤10VDC Offset±4VGeneral CharacteriscticsDisplay7'' TFT LCD,800*480InterfaceRS-232,USB DevicePowerAC220(1±10%)V,50(1±5%)Hz,<60VADimension&Weight363*154*327 mm,Approx,4.8kgs
