• Model NO.：PH,PRP 3081
• HS Code：90278099
• Production Capacity：3200PCS,Month

Basic Info.

Model NO. PH/PRP 3081 HS Code 90278099 Production Capacity 3200PCS/Month

Product Description

ORP-2096 Industrial ORP Meter

ORP-2096 Industrial Online ORP Meter is a precision meter for measurement ORP values. With complete functions, stable performance, simple operation and other advantages, they are optimal instruments for industrial measurement and control of ORP value. Various ORP electrodes can be used in ORP-2096 series of instruments.

Features

LCD display, high-performance CPU chip, high-precision AD conversion technology and SMT chip technology,

multi-parameter, temperature compensation, automatic range conversion, high precision and repeatability

The current output and alarm relay adopt optoelectronic isolating technology, strong interference immunity and

the capacity of long-distance transmission.

Isolated alarming signal output, discretionary setting of upper and lower thresholds for alarming, and lagged

cancellation of alarming

US T1 chips; 96 x 96 world-class shell; world-famous brands for 90% parts;

Technical Indexes

1. Measuring range: -l999~ +1999mV,   Resolution: l mV

2. Accuracy: 1mV,±0.3ºC,            Stability:≤3mV/24h

3.ORP standard solution:6.86,4.01

4.Control range: -l999~ +1999mV

5. Automatic temperature compensation:0~100ºC

6. Manual temperature compensation:0~80ºC

7. Output signal: 4-20mA isolated protection output

8. Communication interface:RS485(Optional)

9. Output control mode :ON/OFF relay output contacts

10. Relay load: Maximum 240V 5A; Maximum l l5V 10A

11. Relay delay: Adjustable

12. Current output load:Max.750Ω

13.Signal impedance input: ≥1x1012Ω

14. Insulation resistance:≥20M

15. Working voltage:220V±22V,50Hz±0.5Hz

16.Instrument dimension: 96(length)x96(width)x115(depth)mm

17.Dimension of the hole: 92x92mm

18.Weight:0.5kg

19. Working condition:

ambient temperature:0~60ºC

Air relative humidity:≤90%

Except for the earth magnetic field, there is no interference of other strong magnetic field around.
