• Model NO.：HZHS-515
• Initial Inflation Pressure：<133PA(Set According to User Requirements)
• The Max Design Pressure of Storage Tank：4.0m PA
• Inflation Rate：>6m³,H
• Final Recovery Pressure：≤1K PA
• Annual Leakage Rate：<1%
• Storage Type：Normal Temperature Liquid
• Noise：≤75dB Sound Pressure Level
• Dust Control：Particle Diameter<1um(Micro Meter)
• Cumulative Failure Free Operation：>5000hours
• Transport Package：Wooden Box with Wr
• Trademark：United
• Origin：Wuhan, China
• HS Code：9027100090

Basic Info.

Model NO. HZHS-515 Initial Inflation Pressure <133PA(Set According to User Requirements) The Max Design Pressure of Storage Tank 4.0m PA Inflation Rate >6m³/H Final Recovery Pressure ≤1K PA Annual Leakage Rate <1% Storage Type Normal Temperature Liquid Noise ≤75dB Sound Pressure Level Dust Control Particle Diameter<1um(Micro Meter) Cumulative Failure Free Operation >5000hours Transport Package Wooden Box with Wr Trademark United Origin Wuhan, China HS Code 9027100090

Product Description

Production Description:
HZHS-515 type SF6 gas recovery device is an integrated recovery device. The device is composed of a recovery system, a vacuum pumping system, a cleaning system, a storage system and a condensing system.

Product Features:
1.Adopt advanced principle and technology, advanced design, complete function, reasonable structure, simple operation.
2.Two-stage rotary vane vacuum pump, the vacuum speed is fast, and equiped with anti oil return device.
3.Automatically confirm and adjust the three phase power supply for electrical system.
4.Using the newest patented technology SF6 special instrument and valves, more reliable than similar products.
5.The device adopts air cooling movable type, and can be used without external water source.

Product Parameters:

Ultimate Vacuum Degree	≤133Pa (special requirement can≤5Pa)	Vacuum Pumping Speed	55m³/h
Initial Inflation Pressure	<133Pa(set according to user requirements)	Recovery Compressor Speed	14.7m³/h
The Max Design Pressure  of Storage Tank	4.0M Pa(customized according to special requirements )	Final Inflation Pressure	≤0.8M Pa
Inflation Rate	>6m³/h	Initial Recovery Pressure	≤0.8M Pa
Final Recovery Pressure	≤1K Pa (standard≤0.05MP or more advanced≤10x133Pa)	Gas Humidity After one time Recovery	80PPM(50kg is for the first time treatment)
Annual Leakage Rate	<1%	Volume of Storage Tank	200L(200kg)
Storage Type	Normal temperature liquid	Power Supply	AC three phase 380V±10%, 50Hz
Noise	≤75dB sound pressure level	Total Power	<XXKW
Dust Control	Particle diameter<1UM(micro meter)	Oil Control	<8PPM
Cumulative Failure Free Operation	>5000hours	Continuous Trouble Free Operation	>1000 hours

Company Profile
Wuhan Hezhong Electric Equipment Manufacture Co., Ltd is a high-tech enterprise professionally engaged in R & D, manufacture and marketing of power testing products, instruments, power industry automation systems for 20 years.We export completed set to Korea, Singapore, Vietnam, India, Ecuador, Paraguay, Pakistan, Philippines, Russia, Italy, Austria, Portugal, Chile such as PD test system, impulse voltage generator, temperature rising test system, transformer comprehensive test system, cable fault detect system and varies of instruments for transformer, circuit breaker, switchgear, lightning arrestor, insulator, cable, battery,SF6 gas and so on.
