• Model NO.：DOG-208F
• Transport Package：Carton
• Specification：26.5*160mm
• Trademark：BOQU
• Origin：Shanghai, China
• HS Code：90278099
• Production Capacity：50, 000 Set,Month

Overview Measuring range0-20ug/L 0-20mg/LElectrode shell material316L stainless steelTemperature compensation resistorNTC: 2.252K 22K Ptl00 Ptl000 and so on.Sensor life>3 yearsCable length5m (double shielded)Detection lower Limit0.1ug/I(ppb)(20°C)Measurement upper limit20mg/l(ppm)Response time≤3min(90%, 20°C)Polarization time>8hMinimum flow rate5cm/s; 515 L/hDrift<3%/monthMeasurement error<±1 ppbOutput current20-25nA/0.01mg/L NoteMaximum current 20-25UaPolarization voltage0.7VZero Oxygen<5ppb(60min)Calibration intervals>60 daysMeasured water temperature0-1300c

Scope of application


Applied to thermal power plants, thermal fermentation industry, etc.Certifications
