• Model NO.：A131
• Type：Concentration Meter
• Transport Package：Export Standard Package
• Trademark：West Tune
• Origin：Shanghai
• HS Code：9027809900
• Production Capacity：50000,Yeas

Basic Info.

Model NO. A131 Type Concentration Meter Transport Package Export Standard Package Trademark West Tune Origin Shanghai HS Code 9027809900 Production Capacity 50000/Yeas

Product Description

A131 Laboratory Benchtop Professional ORP/ Ion/ Water Hardness Test Meter
MEASUREMENT PARAMETERS
A131 meter: Ion Concentration, Water Hardness, mV, Temperature

FEATURES
ORP:
1 point offset calibration allows adjusting the displayed value to a known standard.
Relative and absolute millivolt modes provide the reliable ORP measurements.

ION:
Selectable ion measurement methods, including the direct reading, known addition, known
subtraction, sample addition and sample subtraction.
Selectable concentration units, including the ppm, mg/L, mol/L and mmol/L.
2 to 5 points calibration, providing the 8 concentration points can be selected.
Automatically recognizes the ion selective electrodes, does not need to specify type of ion.
Electrode management is capable of storing the 3 slopes and recalling the calibration data
of each electrode.
Calibration report provides the details of the calibration standard and slope.

WATER HARDNESS:
2 to 5 points calibration from low to high concentrations.
Selectable measurement units ( German degree, English degree, French degree, mg/L and
mmol/L) are used for professional water hardness measurements

GENERAL:
Calibration Due Reminder prompts user to calibrate the meter regularly.
Stability indicator shows when a measurement is recognized as stable.
Auto-Read feature senses and locks the measurement endpoint.
Interval Readings automatically send the measurement data to the computer or printer.
Password protection prevents the unauthorized calibration and settings.
Expanded memory stores and recalls up to 1000 data sets.
Stored readings can be transferred into the computer by USB communication interface.
Reset feature automatically resumes all settings back to factory default options.

METER INCLUDES
A131 meter: ion selective electrode, temperature probe, standard solutions, electrode holder, power adapter.

Optional Electrodes: NH4, Br, Ca, CL, CN, F, NO3, Ag, Na, Cd, Cu, I, Pb, K, S

A131-CN cyanide ion meter does not provide standard solution

Specifications:

Model	A131
mV
Range	±2000.0mV
Accuracy	±0.2mV
Resolution	0.1mV
Ion
Range	0.001~30000 (Deponding on the range of ISE)
Accuracy	±0.5% F.S (Monovalent), ±1% F.S (Divalent)
Resolution	0.001, 0.01, 0.1, 1
Calibration Points	2 to 5 points (0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000)
Measurement Units	ppm, mg/L, mol/L, mmol/L
Measurement Methods	Direct reading, known addition, known subtraction,
	sample addition, sample subtraction
Water Hardness
Range (Concentration)	0.05~200mmol/L
Range (German Degree)	0~1120°dH
Range (English Degree)	0~1404°e
Range (French Degree)	0~2000°fH
Range (CaCO3)	0~19999mg/L
Range (CaO)	0~11220mg/L
Range (Ca2+)	0~8000mg/L
Accuracy	±1% F.S
Resolution	0.001, 0.01, 0.1, 1
Calibration Points	2 to 5 points
Calibration Solutions	0.01, 0.1, 1, 10, 100mmol/L
Temperature
Range	0~105°C, 32~221°F
Accuracy	±0.5°C
Resolution	0.1°C, 0.1°F
Calibration Points	1 point
Calibration Range	Measured value ±10°C
General
Temperature Compensation	0~100°C, 32~212°F, Manual or Automatic
Data Hold	Manual or Auto-Endpoint
Stability Criteria	Standard or High-accuracy
Calibration Due Alarm	1 to 31 days or Off
Interval Readings	10, 30, 60 seconds, 10, 30 minutes or Off
Password Protection	Yes
Reset Function	Yes
Memory	Stores up to 1000 data sets
Output	USB communication interface
Connector	BNC
Display	7 inch TFT LCD
Power	DC12V, using AC adapter, 220VAC/50Hz
Dimensions	240(L)×220(W)×80(H)mm
Weight	1.7kg

 Our Company: Delivery time: usually 3-15 days
Warranty: 12months
Payment methods: T/T, Western Union, Paypal, Credit Card, L/C

Our main lab instruments: mixer, shaker, water quality tester, autoclave, incubator, oven, water treatment(PH/DO/COND/Turbidity meter, pure water system), spectrophotometer, refractometer, peristaltic pump, heating mantle, hot plate, PCR machine, homogenizer, water bath and so on.
