• Model NO.：BK-GR300
• Power Supply：220,110V, 50,60Hz
• Certification：CE
• Weight：10kg
• Customized：Non-Customized
• Block Temperature Range：0ºC~105ºC
• Max. Heating/Cooling Rate：6ºC,S
• Temperature Uniformity：≤±0.2º
• Temperature Accuracy：≤±0.1º
• Display Resolution：0.1ºC
• Transport Package：Carton Package
• Specification：362*256*255mm
• Trademark：BIOBASE
• Origin：China
• Production Capacity：500 Units Per Month

Model

BK-GR300

GradientModule

96 Module

96 wells*0.2ml

9677 Module

96 wells*0.2ml+77wells*0.5ml

384 Module

384 wells

Multi-purpose

9677 Module+In-situ adapter

Display

7 inch color touch screen, graphical display of protocols and running status

Communications

2 USB 2.0 and LAN

Temperature

Block Temperature Range

0ºC~105ºC

Max. Heating/Cooling Rate

6ºC/s

Temperature Uniformity

≤±0.2ºC (at 95ºC)

Temperature Accuracy

≤±0.1ºC (35ºC~100ºC)

Display Resolution

0.1ºC

Mode of Temperature Control

Sim-tube & Block mode

Gradient

Gradient Accuracy

≤±0.1ºC (35ºC~100ºC)

Column Uniformity

≤±0.2ºC (at 95ºC)

Gradient Range

30ºC~105ºC

Temp. Differential Range

1~30ºC

Gradient Capability

12 Column

Software

Max. No. of Programs

Max. 15,000 programs onboard, unlimited storage of protocols with USB flash drive

Max. Step

30steps

Max. Cycle

100 typical cycles, max. 60,000 nesting cycles

Time & Temp. Increment/Decrement

Yes, available for Long PCR & Touchdown PCR

Auto Pause / Auto Restart

Yes

Multi-user Log in

With password-based authentication prevents from view, copy and alteration of protocols

Tm Calculator

Automatically calculate the melting and annealing temperature with two primer sequences

Hold at 4ºC

Yes, an infinite incubation time at low temperature for overnight working

Program Wizard

Yes, create PCR protocols with only a few clicks

Running Report

Yes, provide objective and precise information for the whole experiment

PC Connection

PC remote control to manage more than 120 units of A300 across the network

Heat Lid

Height of Heat Lid

Steplessly adjustable Lid, accommodates all kinds of PCR tubes, strips and plates

Open Method

Innovative "TOP-OPEN" technology realizes open and lift in one step

Heat Lid Temperature Range

30~112ºC

Auto Shut-off

Yes

Others

Power Supply

85~265V, 50~60Hz Max. 600W

Package Size(W*D*H)

362*256*255mm

Gross Weight

10kg
