• Model NO.：GC-102AF
• Certification：CE, ISO, IEC, GMP
• Spectrometer Detector：Si(Li)
• Stationary Phase：Solid Adsorbent
• Mobile Phase：Gas
• Chromatography Type：Gas Chromatography
• Chromatographic Column Type：Capilary Column
• Chromatographic Column Length：10~30cm
• Chromatographic Column Diameter：20~40mm
• Product Name：Laboratory Analysis Gas Chromatography
• Usage：Analytical Chemistry for Separating and Analyzing
• Purpose：Qualitative Analysis, Quantitative Analysis
• Application：Medicine, Petrochemical, Environment, Biochemistry
• Samples：Volatile Organic Compounds
• with Software：Yes
• Temperature Control Area：Column Box, Injector, Detector
• Temperature Control Range：15 C ~ 399 C
• Ignition Gas：Hydrogen and Air
• Delivery Time：10working Days
• Transport Package：Standard Export Case
• Trademark：LABOAO
• Origin：China
• HS Code：9027201100
• Production Capacity：1000sets,Month

Basic Info.

Model NO. GC-102AF Certification CE, ISO, IEC, GMP Spectrometer Detector Si(Li) Stationary Phase Solid Adsorbent Mobile Phase Gas Chromatography Type Gas Chromatography Chromatographic Column Type Capilary Column Chromatographic Column Length 10~30cm Chromatographic Column Diameter 20~40mm Product Name Laboratory Analysis Gas Chromatography Usage Analytical Chemistry for Separating and Analyzing Purpose Qualitative Analysis, Quantitative Analysis Application Medicine, Petrochemical, Environment, Biochemistry Samples Volatile Organic Compounds with Software Yes Temperature Control Area Column Box, Injector, Detector Temperature Control Range 15 C ~ 399 C Ignition Gas Hydrogen and Air Delivery Time 10working Days Transport Package Standard Export Case Trademark LABOAO Origin China HS Code 9027201100 Production Capacity 1000sets/Month

Product Description

Laboratory analysis instrument gas chromatography analyzer for sale

    Gas chromatography (GC) is a common type of chromatography used in analytical chemistry for separating and analyzing compounds that can be vaporized without decomposition. Typical uses of GC include testing the purity of a particular substance, or separating the different components of a mixture (the relative amounts of such components can also be determined). In some situations, GC may help in identifying a compound. In preparative chromatography, GC can be used to prepare pure compounds from a mixture.
    The GC102AF gas chromatograph is a micro-machined, newly designed single detector universal gas chromatograph. The GC102AF is equipped with a single hydrogen flame ionization detector (FID) type gas chromatograph.

Feature:

1. Microcomputerized temperature control with high temperature control accuracy (better than ±0.1°C).
2. The keyboard sets various control and usage parameters (including detector operation parameters). The machine has functions such as self-diagnosis, power-off protection, file storage and recall, limit temperature setting, and FID auto-ignition.
3. Large-screen Chinese character LCD display, large amount of information and intuitive and easy to understand, can accurately display the temperature control set value, actual value, TCD working current, FID amplifier sensitivity and so on.
4. The instrument can be used to fill the packed column. Optional instantaneous vaporization injection, gas injection and gas injection valve, 0.53mm large diameter capillary direct injector.
5. The open microcomputer system can be equipped with RS-232 interface and F-2000 chromatography workstation to realize two-way communication control data processing.
6. Large-capacity oven (330mm × 280mm × 270mm) is convenient for installing packed columns or large-diameter capillary columns.


Specification:

Temperature control:

Temperature control area: column box, injector, detector
Temperature control range: 15 ° C ~ 399 ° C (increment 1 ° C) at room temperature
Temperature control accuracy: better than ± 0.1 ° C (200 ° C measured)

Flame ionization detector (FID)
Detection limit: MFID ≤ 1 × 10-10g / s (sample: C16)
Baseline drift: ≤ 2 × 10-12A / h
