Dycz-25e High-End P4 Vertical Protein Electrophoresis Tank
Size(L×W×H)200x175x160(mm)Weight1.5KGGel quantity1-4 pcsGel size(L×W)100x85mm thickness: 1.0 mm 1.5 mmSample quantity13 or 21 x ( 1-4)Buffer850ml ( 2pcs gel ) / 1200ml ( 4pcs gel )Page gel running time25minutes ( voltage 300V )
-
Dycz-25D Protein Gel Vertical Electrophoresis Cell Chamber
Combs(Four kinds of combs for you to choose)10 well × 1.0mm, 167 μl volume10 well × 1.5mm, 251 μl volume15 well × 1.0mm, 132 μl volume15 well × 1.5mm, 198 μl volumeBuffer volumeabout 13,50mlSize (L×W×H)175 × 163 × 165 (mm)Weightabout 1.0 kg
-
Dycz-24f Lab Biological Protein Analyzer Vertical Electrophoresis Machine
Combs16 well × 1.0mm, 167 μl volume16 well × 1.5mm, 251 μl volume21 well × 1.0mm, 132 μl volume16 well × 1.5mm, 198 μl volumeRuns up16 or 21 samplesBuffer volumeabout 3,500mlSize (L×W×H)300 × 160 × 300 (mm)Weightabout 4.0 kg
-
Dycz-24en Transparent Tank Vertical Protein Gel Cataphoresis Cell
Gel dimension ( L X W)130 × 100 (mm)Runs up12 or 16 samplesComb thickness1.0 and 1.5 (mm)Buffer volumeabout 1,200mlSize (L X W X H)190×120×170(mm)Weightabout 2.0 kgs
-
Dycz-24b High Tranparent Polyacrylamide Gel Electrophoresis Tank
Dimensions (L × W × H)265 × 160 × 185mmGel board specification (L × W)130 × 180mmFull buffer volumeabout 750mlSize (L X W X H)140×125×155 (mm)Weightabout 5 KG
-
Dycz-22A Electrophoresis Cell Vertical System
Gel plate dimension,Specifications of transfer orifice plate(L X W)170 × 170 (mm)Combthickness1mm and 1.5mmFull buffer volumeabout 600mlSize (L X W X H)240×150×240(mm)Weightabout 6 KG
-
Dycp-44p PCR Detection Fast DNA Gel Separate Electrophoresis Analyzer
Gel plate dimension,Specifications of transfer orifice plate(L X W)170 × 140 (mm)Comb(33 teeth )x6 thickness:1.0 (mm)(Standard equip) (17 teeth )x6 thickness:1.5 (mm)(Optional equip)Full buffer volumeabout 200mlSize (L X W X H)210×200×85 (mm)Weightabout 0.5 KG
-
DYCZ-40A Electrophoresis Cell with Cooling Device
Gel plate dimension,Transfer orifice size(L X W)180 × 165 (mm)Total buffer capacityabout 4500 mlInstallation dimensions (L X W X H)250×205×255 (mm)the Weightabout 3KG
