• Model NO.：BK-LCI5100
• Stationary Phase：Solid Adsorbent
• Mobile Phase：Liquid
• Chromatography Type：Liquid Chromatography
• Chromatographic Column Type：Convetional Analytical Column
• Chromatographic Column Length：10~30cm
• Chromatographic Column Diameter：20~40mm
• Model：Bk-Lci5100
• Type：Isocratic Pump
• Flow Rate Range：0.001-10.000ml,Min, in
• Flow Accuracy：≤±0.2% (1.00ml,Min, H2O,R.T.,8.5MPa)
• Flow Precision：Rsd≤0.06% (1.00ml,Min, H2O,R.T.,8.5MPa)
• Maximum Pressure：63MPa
• Pressure Accuracy：≤±3.0%
• Pressure Pulsation：≤0.1MPa
• Wavelength Range：190-800nm
• Wavelength Repeatability：≤0.1nm
• Wavelength Accuracy：≤±1.0nm
• Band Width：6nm
• Response Time：0.0s-5s
• Baseline Noise：≤±0.25×10-5au(Empty Cell254nm, 1.
• Drift：≤0.5×10-4au,H(Empty Cell, 60min)
• Transport Package：Standard Export Package
• Specification：700*570*310mm; 700*570*350mm; 710*583*500mm; 730*
• Trademark：Biobase
• Origin：China
• Production Capacity：500,Month

Model

BK-LCI5100

BK-LCG5100

BK-LCQL5100

Pump

Type

Isocratic Pump

Gradient Pump

Quarternary Low Pressure Pump

Flow Rate Range

0.001-10.000mL/min, in 0.001mL increments

Flow Accuracy

≤±0.2% (1.00ml/min, H2O,R.T.,8.5MPa)

Flow Precision

RSD≤0.06% (1.00ml/min, H2O,R.T.,8.5MPa)

Maximum Pressure

63MPa

Pressure accuracy

≤±3.0%

Pressure pulsation

≤0.1MPa

Composition rang

/

0-100%

0-100%

Composition precision

/

≤0.2%RSD

≤0.3%RSD

UV/VIS

Detector

Wavelength Range

190-800nm

Wavelength Repeatability

≤0.1nm

Wavelength Accuracy

≤±1.0nm

Band Width

6nm

Response Time

0.0s-5s

Baseline Noise

≤±0.25×10-5AU(empty cell, 254nm, 1.0s)

Drift

≤0.5×10-4AU/h(empty cell, 254nm, 60min)

Path length

10 mm(analytical cell)

Light Source

Lamp and Tungsten Lamp

Data-processing Workstation

Sequence tables for any set of samples

Internal and external standard calculation methods

Automatically displays, prints, exports and starts other programs after the completion of a measurement.

Comply with the requirements of the 21 CFR Part 11 directive of the FDA

5100 System Kits

1 Set

5100 System Manager

Integrated A/D converters

Integrated A/D converters

Integrated vacuum degasser, 4 channel

Power Supply

AC110/220V±10%, 50/60Hz

Optional Accessory

Solvent bottle,Column Oven, Auto-sampler,DAD512 Detector, Refractive Index Detector, Evaporative Light Scattering Detector, Fluorescence Detector, PC

Package Size(W*D*H)

700*570*310mm; 700*570*350mm; 710*583*500mm;

730*450*440mm; 600*440*380mm; 770*450*700mm;

Gross Weight

156kg
