GDWG-III NDIR Sulfur Hexafluoride Gas Leakage Detector
HV Hipot Electric Co., Ltd.- Brand：HV Hipot
- Customized：Customized
- Portable：Portable
- Gas：Sf6 etc.
- Type：Non-Dispersive Infrared Analysis
- Response Time：<10s
Base Info
- Model NO.：GDWG-III
- Recovery Time：<15s
- Repeatability：≤±1%
- Power Supply：220V, 50Hz
- Measurement range：0---1500ppm
- Resolution：0.1PPmv
- Dimension：220*250*120mm
- Weight：About 2kg
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9027100090
- Production Capacity：1000PCS,Year
Description
Measuring principle
Non-dispersive infrared sensor (NDIR)
Measuring range
0-1500ppm SF6
Resolution
0.1ppmv
Accuracy
±2%FS (0-1000ppm)
Repeat-ability error
≤±1%
Sensitivity
1ppmv
Response time
≤10s
Recovery time
≤15s
Stability
≤±20ppm, more than 1000 hours
Sampling mode
Pump suction type, flow up to 1L/min.
Zero drift
≤±1%(F.S/year)
Linear error
≤±1%
Peak current
<700mA
Average power
<2W
Operation air pressure
800-1150hPa
Environment humidity
0-95%RH
Storage temperature
-20 ~ +60ºC
Operation temperature
-20 ~ +50ºC
Operation humidity
0-95%(non-condensing)
Working voltage
220VAC±10%,50Hz Or Built-in Li-battery, continuous working 6 hours after full charge.
Dimension
220*250*120mm
Weight
About 2kg
