• Model NO.：BK-LCI1100
• Stationary Phase：Solid Adsorbent
• Mobile Phase：Gas
• Chromatography Type：Liquid Chromatography
• Chromatographic Column Type：Convetional Analytical Column
• Chromatographic Column Length：10~30cm
• Chromatographic Column Diameter：2~5mm
• Model：Bk-Lci1100
• Double Plunger Reciprocating Pump：1 Set
• Flow Range：0.001ml,Min-10.000ml,Min
• Setting Step Size：0.001ml,Min
• Flow Accuracy：≤±0.3% (1.00ml,Min, H2O,R
• Flow Stability：Rsd≤0.1% (1.00ml,Min, H2O,R.T.,8.5MPa)
• Maximum Pressure：42MPa
• Display Pressure Error：≤±3.0%
• Pressure Fluctuation：≤1.0%
• Wavelength Range：190-700nm
• Wavelength Repeatability：±0.1nm
• Wavelength Accuracy：≤±1.0nm
• Spectrum Band Width：8nm
• Power Dissipation：100W
• Transport Package：Standard Export Package
• Trademark：Biobase
• Origin：China
• Production Capacity：500,Month

Model

BK-LCI1100

BK-LCG1100

High Pressure Constant Flow Pump

Double plunger reciprocating pump

1 set

2 sets

Flow Range

0.001mL/min-10.000mL/min

Setting Step Size

0.001mL/min

Flow Accuracy

≤±0.3% (1.00ml/min, H2O,R.T.,8.5MPa)

Flow stability

RSD≤0.1% (1.00ml/min, H2O,R.T.,8.5MPa)

Maximum Pressure

42MPa

Display Pressure Error

≤±3.0%

Pressure Fluctuation

≤1.0%

Power Dissipation

80W

UV/VIS

Detector

Wavelength Range

190-700nm

Wavelength Repeatability

±0.1nm

Wavelength Accuracy

≤±1.0nm

Spectrum Band Width

8nm

Response Time

0.0s-4.9s

Linearity Range

1.8AU (5%)

Baseline Noise

≤±1×10-5AU

Baseline Drife

≤2.0×10-4AU/h

minimum Detectable Concentration

4.0×10-9g/mL(Naphthalene in Methanol Solution)

Detector Cell

Optical Path--10mm, Volume--10μL

Light Source

Lamp

Power Dissipation

100W

Gradient Mixer

/

GM1100

Sampler Injector

1

Supersil ODS2 5μm ID4.6×200mm

1

Workstation (Without Computer & Printer)

1

Valve Mounting Frame

1

Kits

Isocratic System Kits

Gradient System Kits

Power Supply

AC110/220V±10%, 50/60Hz

Optional Accessory

Column Oven
