Dropping Point Tester/ Dropping Point of Lubricating Grease

Beijing Samyon Instruments Co., Ltd.
  • Warranty：1 Year
  • Power Supply：AC 220 V±10%, 50 Hz
  • Oil Bath：600 Ml Beaker.
  • Heater：Tubular. Power 800 W.
  • Stirring Motor：Rotating Speed 60 Rpm
  • Ambient Temperature：-10oc~+40 Oc

Base Info

  • Model NO.：SY-4929A
  • Relative Humidity：=<85%
  • Transport Package：Carton Case
  • Specification：SGS
  • Trademark：SAMYON
  • Origin：Cn
  • HS Code：9031809090
  • Production Capacity：100sets Per Month

Description

1. Power supplyAC 220 V±10%, 50 Hz2. Oil bath600 ml beaker.3. Grease cupMade of chrome plated brass. Its inner diameter is about 9.92 mm and the diameter of orifice for dropping oil is 2.8 mm. The height of the cup is about 12 mm.4. Test tubeA tube made of heat-resistant glass with rim. Its inner diameter is 11.1 mm to 12.7 mm. There are three indentations at about 19 mm from the bottom, equally spaced on the circumstance. These indentations are used for supporting the grease cup.5. Thermometer-5ºC~300 ºC,scale value is 1 ºC. Its total length is 390 mm and the depth immersed is about 76 mm.6. HeaterTubular. Power 800 W.7. Stirring motorRotating speed 60 RPM8. Ambient temperature-10ºC~+40 ºC9. Relative humidity≤85%10. Maximum power consumption900 W11. Dimension350mm×180mm×410mmDropping Point Tester/ Dropping Point of Lubricating GreaseDropping Point Tester/ Dropping Point of Lubricating Grease Dropping Point Tester/ Dropping Point of Lubricating GreaseDropping Point Tester/ Dropping Point of Lubricating Grease
