• Model NO.：HT-LH361
• Physical Analysis Type：Thin-Film Capacitor
• Chemical Analysis Type：None
• Operating Mode：Automatic
• Heating Mode：Step Heating
• Off Mode：Automatic
• Test Principle：Electric Capacity
• Transport Package：Cartoon Box
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. HT-LH361 Physical Analysis Type Thin-Film Capacitor Chemical Analysis Type None Operating Mode Automatic Heating Mode Step Heating Off Mode Automatic Test Principle Electric Capacity Transport Package Cartoon Box Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

 Technical Specifications:
   Measurement Principle: Electric capacity
   Display Mode: 4 digit high-light LED, display resolution 0.1%
   Measurement Range: Volume absolute humidity: 0~40.0%VOL
                                      Relative humidity: 0~100%RH
                                      High-temperature dew point: -20ºC~+100ºC
                                      (Default: Volume absolute humidity. Only one mode can be displayed and cannot be changed once leaving the factory. Please indicate the display mode you need when ordering.)
   Measurement Accuracy: ≤±1.5%FS comprehensive accuracy, high-temperature dew point ≤±0.5ºC
   Repeatability: ≤±1.0%FS
   Response Time: T90≤30S
   Output Port: 4-20mA.DC (Non-isolated output, load resistance<1KΩ)
                       2 ways of programmable alarm output (Dry contact type, maximum load 220VAC/2A)
   Communication Mode: RS485 (default) or RS232
   Power Supply: AC220V±10% 50/60Hz, power dissipation< 80VA (heat tracing equipped), 20VA (heat tracing not equipped)
   Operation Temperature: Instrument: -10ºC~+50ºC, probe: 0~170ºC
   Sampling Mode: In-site sampling
   Protection Level: Probe material: 316F, gauge head: IP65
   Probe Length: Normal length 0.5m,1.0m,1.2m, other length is customizable (≤1.8m)
   Sensor Service Life: >24 months (under normal conditions of use)
   Instrument Weight: Net weight 8.2Kg (1.0m)
   Installation Plug-in, standard DN65 flanged mounting


Features:   a.   Integrated design makes it easy to install and is able to reduce the impact on measurement value from outer interference;   b.   Original imported sensor has high measurement accuracy, strong anti-interference capacity and rapid response speed, and it is high-temperature resistant and weak-acid resistant;   c.   Unique heating tracing design could prevent the condensation of sulfide and water vapor effectively;   d.   The menu lock function could prevent mis-operation, which may change instrument parameters and affect its performance;   e.   Automatic temperature compensation function could eliminate the impact of environmental temperature changes on the measurement value;   f.   Expanded function can be added to do an accurate measurement of the high-temperature dew point value;   g.   Two-stage filter could filter dust and acid fluid effectively;   h.   The probe is made of 316L and is strongly corrosive-resistant. Other material can be customized or spraying the probe with corrosive-resistant coat for severe application;    i.   The protection level of the gauge head is IP65 and is suitable for outdoor severe environment   j.   Display mode in volume absolute humidity, relative humidity and high-temperature dew point are available. (Display mode can not be changed after leaving the factory, please indicate the display mode you need when ordering.)
Application:
    It is applied to the humidity measurement of desulfurization equipment, ultra-low emission, VOC and other occasions in gas on-line continuous monitoring system CEMS, and it can also be used for humidity control in industries of wood, building materials, papermaking, chemical industry, pharmaceutical industry, tobacco, printing and dyeing, low-temperature economizer, cloth bag dust removal, etc.
Note: If the environment is of low temperature, high humidity and high dust, we would provide you reasonable solutions on flue gas humidity.


Order Notice (Please indicate following messages when placing orders)
   Sample gas temperature
   Probe length
   Duty parameters (corrosivity, air speed, dust content)
