• Model NO.：DW-CS8820
• Frequency：50±0.5Hz
• Performance：Automation
• Function：Storage
• Weight：100-500Kg
• Power Source：AC220V±22V
• Customized：Customized
• Transport Package：Standard Export Package with Pure English
• Trademark：DRAWELL
• Origin：China
• HS Code：9027809900
• Production Capacity：300 Piece,Month

Overview Product Description

DW-CS-8820 Type High-frequency Infrared Carbon&Sulfur Analyzer

 Application fieldsInfrared Carbon & Sulfur Analyzer, with infrared analysis techniques and arc burner, Testing the mass fraction of C, S of steel, iron, alloy, mold and cores, nonferrous metal, cement, ore, coke, catalyst, magnetic materials, ceramic, inorganic substance, black lead, refractory matter, battery matter, plant and other materials. Main technical parameters

Measuring rangeC: 0.0001%-10.0000% (can extend to 99.9999%)
S: 0.0001%-3.5000% (can extend to 99.9999%)Analysis of errorWith GB / T20123-2006/ ISO15350: 2000 standardAnalysis time25-60 seconds can be set ( usually 35 seconds)High frequency furnacepower ≥2.7KVA Oscillation frequency:20MHzElectronic balanceweight the sample in variable amount  Accuracy of reading:0.0001gWorking environmentindoor temperature:10-30ºC,relative humidity:<90%Power supplyvoltage:AC220V±5%,frequency:50Hz±2%OxygenPurity: ≥99.5%,  input pressure : 0.18MPa + 5% Main features(1). Adopting the double CPU design, electronic circuit integration degree is highly, steady and reliable, which can settle the high-frequency interference thoroughly.
(2). The special new platinum infrared light source, Gold plated carbon sulfur analysis pool and high precision pyroelectric infrared detector to make the apparatus' measurement more accurate.
(3). Adopting the high power and quick frequency circuit design, which using 6KVA high frequency power tube(actual use of power is about 2.5KVA, it can turn on to work itself), to reduce the high frequency combustion system load and to increase the using time.
(4). Furnace head automatic cleaning device, patent technology supply system and -0.4mm amd hole metal filter to make the dust and gas seperated, reducing the dust on the result of analysis.
(5). Specialized analysis software of many different language owns following functions: curve/data storage, blank deduction, parameter determination, channel choosing, data statistics, results correction, breakpoint correction, curve comparison, system diagnosis, automatic/manual printing analysis results etc.


Spare parts listNamespecificationUnitQtyRemarksPressure reducing valve Piece1With a special connectorTungsten particle Kg1 Pure ironTaigang Cbottle1 Quartz tube Piece1With this machineDust  cleaning tube Piece2 Copper crucible supporting Piece1 Porcelain crucible supporting Piece2With this machinePorcelain crucible Carton1 Stainless steel brush Piece2 Steel brush Piece1 Tweezers Piece1 Samples of spoonLarge, medium and smallSet1 Paint brush Piece1 Combination tool Set1 PVC tube4mm×6mmMeter10 SiliconeRedPiece1 O type Ring13mm×1.9mmPiece2 O type Ring37mm×3.1mmPiece2 Vacuum silicone bottle1 Fuse4A,20APiece2 Fast-plug connectorsPC06-01Piece2 Fast-plug connectorsPC06-02Piece2 Multi-purpose socket10APiece1 Chip2003Piece2 ChipTLP521-4Piece2 Desiccant125g/ bottlebottle1 Ash discharge tubesilica gelPiece1
