Biobase Bk-Lci3100 High Performance Liquid Chromatography
Biobase Biodustry (Shandong) Co., Ltd.- Appliance：The Analysis of Environmental Samples
- Ray Type：Gamma Ray Spectrometer
- Gaspath System：Single
- Energy Resolution：≤7%
- Spectrometer Detector：SDD
- Stationary Phase：Solid Adsorbent
Base Info
- Model NO.：BK-LCI3100
- Mobile Phase：Gas
- Chromatography Type：Liquid Chromatography
- Chromatographic Column Type：Narrow Bore Column
- Chromatographic Column Length：10~30cm
- Chromatographic Column Diameter：20~40mm
- Model：Bk-Lci3100
- Quantity：1 Set
- Flow Rate Range：0.001ml,Min-10.000ml,Mi
- Flow Accuracy：≤±0.2% (1.00ml,Min, H2O,R
- Flow Precision：Rsd≤0.075% (1.00ml,Min, H2O,R.T.,8.5MPa)
- Maximum Pressure：45MPa
- Pressure Accuracy：≤±3.0%
- Pressure Pulsation：≤0.1MPa
- Wavelength Range：190-700nm
- Wavelength Repeatability：≤0.1nm
- Wavelength Accuracy：≤±1.0nm
- Band Width：8nm
- Response Time：0.0s-5s
- Baseline Noise：≤±0.5×10-5au
- Drift：≤1.0×10-4au,H
- Transport Package：Standard Export Package
- Specification：600*440*380mm*4
- Trademark：Biobase
- Origin：China
- Production Capacity：500,Month
Description
Model
BK-LCI3100
BK-LCGH3100
BK-LCQL3100
High Pressure Constant Flow Pump
Quantity
1 Set
2 Set
1 Set
Flow Rate Range
0.001mL/min-10.000mL/min
Flow Accuracy
≤±0.2% (1.00ml/min, H2O,R.T.,8.5MPa)
Flow Precision
RSD≤0.075% (1.00ml/min, H2O,R.T.,8.5MPa)
Maximum Pressure
45MPa
Pressure accuracy
≤±3.0%
Pressure pulsation
≤0.1MPa
UV/VIS
Detector
Wavelength Range
190-700nm
Wavelength Repeatability
≤0.1nm
Wavelength Accuracy
≤±1.0nm
Band Width
8nm
Response Time
0.0s-5s
Baseline Noise
≤±0.5×10-5AU
Drift
≤1.0×10-4AU/h
Path length
10 mm(analytical cell)
Light Source
Lamp
Low-Pressure Gradient Unit
Integrated vacuum degasser
/
/
4 channel
Composition Rang
0-100%
Composition Precision
≤0.2% RSD
Composition Accuracy
≤±2.0%
Data-processing Workstation
Internal and external standard calculation methods
Automatically displays, prints, exports and starts other programs after the completion of a measurement.
Comply with the requirements of the 21 CFR Part 11 directive of the FDA
3100 System Kits
1 Set
Power Supply
AC110/220V±10%, 50/60Hz
Optional Accessory
Column Oven, Autosampler, Degasser, Diode Array Detector, Refractive Index Detector, Evaporative Light Scattering Detector, Fluorescence Detector
Package Size(W*D*H)
600*440*380mm*4
Gross Weight
68kg
