• Model NO.：IF-069
• Function：Test Grease ,Oil Content in Water
• Transport Package：Standard Export Wooden Case
• Specification：ISO,CE
• Trademark：TOP
• Origin：Chongqing, China
• HS Code：9027809900
• Production Capacity：500 Sets Per,Mouth
• Package size per unit product：71.00cm * 57.00cm * 39.00cm
• Gross weight per unit product：25.000kg

Basic Info.

Model NO. IF-069 Function Test Grease /Oil Content in Water Transport Package Standard Export Wooden Case Specification ISO/CE Trademark TOP Origin Chongqing, China HS Code 9027809900 Production Capacity 500 Sets Per/Mouth

Packaging & Delivery

Package size per unit product 71.00cm * 57.00cm * 39.00cm Gross weight per unit product 25.000kg

Product Description

Operation Principle

Infrared oil measuring instrument uses infrared spectrophotometry to scan the sample for monochromatic spectrum. It can display and print the wave position of the sample spectrum and absorption peak, and can measure the oil concentration in the sample.

Structure
1. The instrument host consists of optical system, electrical system and microcomputer data processing system.

2. Automatic jet extractor. (optional)

3. Laptop. (optional)


Characteristics

1. Detachable integrated optical system, the instrument is small in size, light in weight and good stability;
2. The electric modulation light source is used to reduce the heat generation intensity of the light source, which is beneficial to the system heat dissipation;
3. No mechanical cutting motion device, which simplifies the structure of the instrument and improves the reliability of the instrument;
4. The sensor signal processing adopts a lock-in amplifier circuit to improve the signal-to-noise ratio (SNR) and detection limit of the instrument;
5, the instrument can check whether the purity of the extractant meets the measurement needs;

6. Various non-carbon chlorine and carbon chloride organic solvents such as tetrachloroethylene and carbon tetrachloride can be used as extracting agents;
7, can be used as an infrared spectrophotometer;
8. The colorimetric cell structure is suitable for 1 to 5 cm cuvettes;
9. The structure is simple, and the instrument optical system and electrical system are highly integrated;
10, the operation is simple, the measurement speed is fast, the sample is measured once, the full spectrum scan is about 40 seconds, and the non-dispersion method is 2 seconds;
11. The software is powerful, the measurement data and spectrum can be saved to the hard disk, and the spectrum can be inquired and printed at any time, and has functions such as automatic zero adjustment and regression equation calculation.

Basic measurement range	0.001~100mg/L ( 4cm cuvette)
Detection limit	<0.12mg/L (extraction agent, Direct measurement )
	<0.0012mg/L (Oil concentration in water samples)
Measurable concentration	≤640000mg/L(Dilution measurement);≤100% oil
Testing accuracy	±0.5 (<10 mg/L)
	±2% (10~80mg/L)
Zero stability	±1%/24 hours
Repeatability	Relative standard deviation RSD≤1%
Linear	R>0.999
Wave number range	3400cm-1~2400cm-1/85000px-1~60000px-1 (2941nm~4167nm)
Wave number accuracy	2cm-1
Wavenumber repeatability	2cm-1
Absorbance range	0.0000~2.000AU
Baseline drift	Absorbance<0.001AU/60min
Sample analysis time	Full spectrum scan:40 seconds or so;Non-dispersive method: 2 seconds
Dimensions	540mm×360mm×150mm
Weight	15Kg
Power supply	(220V/50Hz)±10%
Environmental requirements	5ºC~35ºC;20%~80%RH,No condensation; no strong magnetic interference
