GDPDS-341 SF6 Electrical Insulation State Comprehensive Analyzer
HV Hipot Electric Co., Ltd.- After-sales Service：yes
- Warranty：1 year
- Brand：HV HIPOT
- Customized：Customized
- Portable：Portable
- Gas：SF6
Base Info
- Model NO.：GDPDS-341
- Type：Electrochemical Gas Analyzer
- Power supply：110-220VAC±10%, 50Hz
- Use environment temperature：-20~+60 centigrade
- Environment humidity：90%RH
- Dimension：570*418*320mm
- Weight：about 18kg
- Transport Package：Export Wooden Box
- Specification：395*295*155mm
- Trademark：HV HIPOT
- Origin：China
- HS Code：9031809090
- Production Capacity：600set,Year
Description
Working environmentWorking temperature -20ºC~50ºC Environment humidity 0~90%RH IP level 54
SF6 gas analysis part
SF6 Humidity
-20→-60ºC Td 10s[240s]
CO: 0 ~ 500ppmv
HF: 0 ~ 50ppmv
SF6 Decomposition Products: 250-300ml/min
Sample gas flow rate: no-effect
Humidity: 90%RH
UHF sensor 1 piece
Ultrasonic sensor 1 piece
TEV sensor 1 piece
HFCT 1 piece
Signal connection cable 1 piece
Connectors 1 set
Teflon pipe (include flow adjustment valve and fast connector) 1 set
Tail pipe 1 set
Spare parts 1 set
Charger 1 piece
User's Guide 1 piece
Test Report 1 piece
SF6 gas analysis part
SF6 Humidity
- Measurement method: Resistive and Capacitive measurement principle
- Measurement range: dew point -80ºC--+20ºC (support ppmv)
- Accuracy: ±1ºC
- Response time: 63% [90%]
-20→-60ºC Td 10s[240s]
- Resolution: 0.01ºC
- Repeatability: ± 0.5 ºC
- Display unit: ºC, ppm, ºCP20(converted value at 20ºC)
SF6 Purity
- Measurement method: Infrared Measurement Principle (NDIR series sensors)
- Measuring range: 0 ~ 100% SF6
- Response time: [90%] 60s
- Accuracy: ± 0.5%FS
- Repeatability: ± 0.5%
- Resolution: 0.01%
- Display unit: %
SF6 Decomposition Products
- Measurement method: Electrochemical Measurements Principle (Electrochemical series sensors)
- Measurement range: H2S: 0 ~ 100ppmv
CO: 0 ~ 500ppmv
HF: 0 ~ 50ppmv
- Resolution: 0.5ppmv
- Display unit: ppmv
- Dew point measurement: SF6 and other gas: 400-600ml/min
SF6 Decomposition Products: 250-300ml/min
- Flow display: 0-1000mL digital flow meter
- Sample gas pressure: ≤1MPa
- Sensor protection: Stainless steel sintered filter
- Power supply: 110-220VAC±10%, 50Hz, AC/DC use, over-charge protection, continuous working is no lower than 8hours.
- Use environment temperature: -20--+60ºC
- Operation environment: temperature: -35 - 70ºC
Sample gas flow rate: no-effect
Humidity: 90%RH
- Dimension: 570*418*320mm
- Weight: about 18kg.
Accessories
Main Tester 1 pieceUHF sensor 1 piece
Ultrasonic sensor 1 piece
TEV sensor 1 piece
HFCT 1 piece
Signal connection cable 1 piece
Connectors 1 set
Teflon pipe (include flow adjustment valve and fast connector) 1 set
Tail pipe 1 set
Spare parts 1 set
Charger 1 piece
User's Guide 1 piece
Test Report 1 piece
