Bi-650-M Industrial Water Conductivity/ TDS Test Meter
Hangzhou West Tune Trading Co., Limited- After-sales Service:Online After-Sales Service
- Warranty:1 Year
- Appliance:Food Analysis, Medical Research, Biochemistry
- Portable:Portable
- Certification:CE
- Type:Conductivity Meter
Base Info
- Model NO.:BI-650-M
- Conductivity Range:0.01~20.00,200.0,2000µs,Cm,20.00,200.0ms,Cm
- TDS Range:0~10.00,100.0,1000ppm,10.00,100.0ppt(Max. 200ppt)
- Temperature Range:0~100°c, 32~212°f
- Transport Package:Export Standard Package
- Trademark:West Tune
- Origin:Shanghai
- HS Code:9030899090
- Production Capacity:50000,Yeas
Description
Basic Info.
Model NO. BI-650-M Conductivity Range 0.01~20.00,200.0,2000µs/Cm,20.00,200.0ms/Cm TDS Range 0~10.00,100.0,1000ppm,10.00,100.0ppt(Max. 200ppt) Temperature Range 0~100°c, 32~212°f Transport Package Export Standard Package Trademark West Tune Origin Shanghai HS Code 9030899090 Production Capacity 50000/YeasProduct Description
BI-650-M Industrial Water Conductivity/ TDS Test MeterMEASUREMENT PARAMETERS:
Conductivity, Total Dissolved Solids, Temperature
Features:
1. Economical online conductivity controller contains the TDS measurement mode.
2. 1 to 3 points push-button calibration, automatically recognizes the calibration solutions.
3. Selectable cell constant (0.1/1/10), temperature coefficient and TDS conversion factor
4. Automatic Temperature Compensation provides accurate reading over the entire range.
5. Low or high alarm limit can be set by user and automatically activate an external device.
6. 4 to 20mA output signal meets industry standard.
7. Manual temperature calibration corrects the temperature deviation.
8. Setup menu allows setting the 9 parameters, including the number of calibration points temperature unit, alarm limits, hysteresis value, etc.
9. Reset feature automatically resumes all settings back to factory default options
Specifications:
Model | BI-650-M |
Conductivity | |
Range | 0.01~20.00, 200.0, 2000µS/cm, 20.00, 200.0mS/cm |
Accuracy | ±1% F.S |
Resolution | 0.001, 0.01, 0.1, 1 |
Calibration Points | 1 to 3 points |
Calibration Solutions | 84uS/cm, 1413uS/cm, 12.88mS/cm, 111.8mS/cm |
TDS | |
Range | 0~10.00, 100.0, 1000ppm, 10.00, 100.0ppt (Max. 200ppt) |
Accuracy | ±1% F.S |
Resolution | 0.01, 0.1, 1 |
TDS Factor | 0.1~1.0 (Default 0.5) |
Temperature | |
Range | 0~100°C, 32~212°F |
Accuracy | ±1°C |
Resolution | 0.1°C, 0.1°F |
Calibration Points | 1 point |
Calibration Range | Measured value ±10°C |
Communication | |
Signal Output | 4~20mA |
Load | Max. 500Ω |
Low or High Alarm | 0.02uS/cm~20.0mS/cm, selectable |
Communication Interface | RS485 |
Connection Terminals | Detachable screw terminals |
General | |
Temperature Compensation | 0~100°C, 32~212°F, Automatic |
Temperature Coefficient | 0.0~10.0%/°C, linear |
Cell Constant | K=0.1, 1, 10 |
Reference Temperature | 25°C |
Environmental Conditions | Ambient temperature < 60°C, relative humidity < 80% |
Power | DC24V |
Dimensions | 96(L)×96(W)×75(H)mm |
Weight | 350g |
