• Model NO.：GDSF-311WP
• Portable：Portable
• Physical Analysis Type：Gas Chromatography Method
• Chemical Analysis Type：TCD technology.
• Operating Mode：Touch Screen
• Heating Mode：Standard Heating
• Off Mode：Automatic
• Measuring range：0 ~ 100% SF6.
• Power supply：220VAC±10%, 50Hz, AC,DC use
• Use environment temperature：-20--+60 centigrade
• Weight：2kg
• Transport Package：Export Wooden Box
• Specification：395*295*155mm
• Trademark：HV Hipot
• Origin：China
• HS Code：9025800000
• Production Capacity：3000set,Year

SF6 Humidity

Measurement method

 Resistive and Capacitive measurement principle

Measurement range

 dew point -80ºC--+20ºC(support ppmv)

Accuracy

 ±1ºC

(when the dew point temperature is below 0 ºC, the sensor output is the frost point)

Response time

 63% [90%]

+20→-20ºC Td 5s[45s]

-20→-60ºC Td 10s[240s]

Resolution

 0.01ºC

Repeatability

 ± 0.5 ºC

Display unit

 ºC, ppm, ºCP20(converted value at 20ºC)

Gas flow

 400-600ml/min

Flow display

 0-1000mL digital flow meter

Sample gas pressure

 ≤1MPa

SF6 Purity

Measurement method

 Infrared measurement principl

Measuring range

 0 ~ 100% SF6.
Response time [90%] 60s

Accuracy and repeatability

 ± 0.5%, nothing to do with the flow.

Power supply

 220VAC±10%, 50Hz, AC/DC use, over-charge protection, continuous working is no lower than 8hours.

Use environment temperature

 -20--+60ºC

Environment humidity

 90%RH

Measurement value influence

 No effect of pressure and flow

Dimension

 395*295*155mm

Weight

 about 2kg
