Biobase Automobile Exhaust Analyzer Vehicle Gas Analyzer
Biobase Biodustry (Shandong) Co., Ltd.- Brand：Biobase
- Customized：Non-Customized
- Portable：Portable
- Certification：CE
- Gas：Co,Hc,CO2,O2,No
- Hc：0~10000*10-6(Ppm)Vol
Base Info
- Model NO.：BK-EA501
- Co：0~10*10-2(%)Vol
- CO2：0~20*10-2(%)Vo
- O2：0~25*10-2(%)Vol
- Nox：0~5000*10-6(Ppm)Vol
- Stability：Moment Drift No More Than 3%
- Response Time：95% Response Is Not
- Power Supply：AC 110,220V, 50,60Hz
- Packing Size：680*385*265mm
- Gross Weight：12kg
- Transport Package：International Standard Package
- Specification：680*385*265mm
- Trademark：Biobase
- Origin：Jinan, Shandong
- Production Capacity：1000units,Month
Description
Model
BK-EA201
BK-EA301
BK-EA401
BK-EA501
Measuring
Range
HC 0~10000*10-6(ppm)vol
CO: 0~10*10-2(%)vol
HC 0~10000*10-6(ppm)vol
CO: 0~10*10-2(%)vol
NOx: 0~5000*10-6(ppm)vol
HC 0~10000*10-6(ppm)vol
CO: 0~10*10-2(%)vol
CO2: 0~20*10-2(%)vol
O2: 0~25*10-2(%)vol
HC 0~10000*10-6(ppm)vol
CO: 0~10*10-2(%)vol
CO2: 0~20*10-2(%)vol
O2: 0~25*10-2(%)vol
NOx: 0~5000*10-6(ppm)vol
Indicating
Error
HC±12*10-6(ppm)vol
CO±0.06*10-2(%)vol
HC±12*10-6(ppm)vol
CO±0.06*10-2(%)vol
NOx±25*10-6 (ppm)vol
HC±12*10-6(ppm)vol
CO±0.06*10-2(%)vol
CO2±0.5*10-2(%)vol
O2±0.1*10-2(%)vol
HC±12*10-6(ppm)vol
CO±0.06*10-2(%)vol
CO2±0.5*10-2(%)vol
O2±0.1*10-2(%)vol
NOx±25*10-6 (ppm)vol
Stability
Moment drift≤±3%
Repeatability
≤±C2%
Response Time
95% response is not more than 10 seconds
Preheating Time
8min ( preheating 3min emergency detection )
Power Supply
AC 110/220V±10%,50/60Hz
Packing Size(W*D*H)
680*385*265mm
Gross Weight
12kg
Applications:
* Used to measure vehicle emissionsof gasconcentration
Features:
* With built-in printer
* With a high-brightness digital display
* Automatic zero, linear automatic data processing, auto-alarm when the gas line blocking
