• Model NO.：BK-AII
• Weight：0-50kg
• Customized：Non-Customized
• Block Temperature Range：0ºC-105ºC
• Temperature Uniformity：≤ ±0.2ºC
• Max. Heating Rate：5ºC,S
• Display Resolution：0.1ºC
• Mode of Temperature Control：SIM-Tube & Block Mode
• Transport Package：Cartoon Package
• Specification：BK-AII
• Trademark：BIOBASE
• Origin：China
• Production Capacity：50000 PCS Per Year

Model

BK-AI

BK-AII

Optional Module

Standard Thermal Cycler

Gradient Thermal Cylcer

96 Module: 96 wells*0.2ml

9677 Module: 96 wells* 0.2ml+77 wells*0.5ml

384 Module: 384 wells

Multi-purpose Module: 9677 Module+In-situ Adapter

Heating And Cooling Technology

Newest generation Peltier-based technology, with long life up to 1,000,000 cycles

Display

7° Color Touch Screen, graphical display of protocols and running status

Language

Bilingual: English and Chinese

USB Flash Drive

Unlimited storage of protocols with USB flash drive

Communications

USB 2.0, LAN and RS232

Temperature

Block Temperature Range

0ºC-105ºC

Max. Heating Rate

5ºC/s

Max. Cooling Rate

5ºC/s

Temperature Uniformity

≤ ±0.2ºC(at 95ºC)

Temperature Accuracy

≤ ±0.2ºC(35ºC-100ºC)

Display Resolution

0.1ºC

Mode Of Temperature Control

Sim-tube & Block mode

Ramping Rate Adjustable

Yes

Gradient

Gradient Accuracy

/

≤ ±0.1ºC(35ºC-100ºC)

Column Uniformity

/

≤ ±0.2ºC (at 95ºC)

Gradient Range

/

35ºC-100ºC

Temp. Differential Range

/

Max.30ºC

Gradient Capability

/

12 Column

Heated Lid

Height of Heated lid

Steplessly Adjustable lid, accommodates a wide range of PCR tubes and plates

OpenMethod

Innovative TOP-OPEN technology realizes most easy lid-open

Heated Lid Temperature Range

30ºC-105ºC

Auto Shut-off

Yes

Software

Max. Number of Programs

Max.10,000  programs onboard, unlimited storage of protocols with USB flash drive

Max.Step

30 steps, multiple nesting cycle available

Max.Cycle

100 typical cycles(duplex nesting 10,000 cycles)

Time & Temp. Increment/Decrement

Yes, available for long PCR & Touchdown PCR

Auto Pause/Auto Restart

Yes

Multi-user Log In

With password-based authentication, protect personal protocols

Tm Calculator

Automatically calculates the melting and annealing temperature with two primer sequences

Hold At 4ºC

Yes, a below ambient temperature incubation allow PCR results storage overnight

ProgramWizard

Yes, create PCR protocols with only a few clicks

Running Report

Yes, provide precise data support for analyzing of experimental results

PC Connection

PC remote control to manage more than 100 units of A100/A200 across the network

Other Features

Power

Global switch power supply:85V-265V,50-60Hz Max.600W

Approvals

ISO 9001:2000,CE

Packing Size(L*W*H)

430*340*335mm

Gross Weight

9.8kg
