• Model NO.：HST2610
• Origin：Shandong
• HS Code：9017800000
• Production Capacity：50000 Set,Year

Basic Info.

Model NO. HST2610 Origin Shandong HS Code 9017800000 Production Capacity 50000 Set/Year

Product Description

HST2610 Coating Ultrasonic Thickness Gauge Remarks:
can measure the thickness of non-magnetic coating layers covered on magnetic substrate. Such as:
non-magnetic (aluminum, chrome, copper, enamel, rubber, paint) covered on magnetic substrate
(steel, alloy and magnetic stainless steel)
It also can measure the thickness of non-conductive coatings layers covered on conductive substrate.
Such as: (enamel, rubber,paint, vanish, plastic anodic oxide layer) covered on conductive substrate
(aluminum, brass,  zinc and nonmagnetic stainless steel).Specifications:

Main feature:
With different probe: KY100can measure the thickness of non-magnetic coating layers covered on
magnetic substrate. Such as: non-magnetic (aluminum, chrome, copper, enamel, rubber, paint) covered on
magnetic  substrate (steel, alloy and magnetic stainless steel)
It also can measure the thickness of non-conductive coatings layers covered on conductive substrate.
Such as: (enamel, rubber, paint, vanish, plastic anodic-oxide layer) covered on conductive substrate
(aluminum, brass,  zinc and nonmagnetic stainless steel).


Technical Parameters

Product Name	Coating Thickness Gauge
Model	HST2610
Range	0- 1250μm, depends on probes, MAX 10mm for the probe F10
Resolution	0. 1 μm
Display	128x64 LCD with backlight
Accuracy	±2%H+ 1um Note: H is thickness reading
Weight	340g
Size	115*67*31mm
