Automatic ASTM D445 Hydraulic Oil Viscosity Test Kit (TPV-8)
Chongqing TOP Oil Purifier Co., Ltd.- Power：Electronic
- Usage：Auto Testing Machine
- Temperature Control Accuracy：0.1 ′c
- Timing Accuracy：0.1s
- Transport Package：Wooden Case
- Specification：CE,ISO
Base Info
- Model NO.：TPV-8
- Trademark：TOP
- Origin：China
- HS Code：9027809900
- Production Capacity：200 Sets,Month
Description
Basic Info.
Model NO. TPV-8 Trademark TOP Origin China HS Code 9027809900 Production Capacity 200 Sets/MonthProduct Description
Automatic ASTM D445 hydraulic oil viscosity test kit(TPV-8)Product Application
The Determinator, applicable to GB26588, GB1814, ASTM D445, IP71, and other determining methods, adopts precise digital
temperature controller to control temperature, with advantage of digital display, high accuracy of temperature control, time-reckoning via digital stopwatch and uniform temperature of homoeothermic waterbath. It not only can be installed with four
viscometers for testing simultaneously, but also can be high-viscosity homoeothermic waterbath for other testing.
Product Features
1. Adopts imported precise digital temperature controller to control temperature of bathtub and highlighted digital stopwatch for
timing, easy to operate.
2. Equipped with ten-liter homoeothermic bathtub with advantages of uniform temperature and effective temperature control.
3. Equipped with stainless steel heater and components, anti-corrosion and durable; and employed with annular typed daylight
lamp for lighting, easy to observe.
4. The Determinator, with four viscometer installing holes, can test four types of oil for testing simultaneously.
5. Capillarimeter clutch is three-point vertical type, with advantage of flexible and convenient operation and reliable grasp.
Technical Parameter
| Performance Standards | GB265-88 ,GB1814,ASTM D445,IP71, etc. |
| Capillary Viscometer | Conform to SH/T0173-92 Technical Conditions of Glass Capillary Viscometer Conform to JJG155 Verification Regulation of Routine Capillary Viscometer |
| Method of Display | Precise digital temperature controller Highlighted digital stopwatch calculagraph |
| Temperature Control Range | Arbitrary setting between room temperature and 150ºC |
| Testing Range | Kinematic viscosity:0.5~20000mm2/ Kinetic viscosity:0.3~40000mPa.s |
| Temperature Control Accuracy | ±0.1ºC |
| Timing Accuracy | ±0.1S |
| Timing Range | 0.1S-999.9S |
| Homoiotherrmal Bathtub | 300×300mm double layer |
| Temperature Testing Components | Precise imported platinum electric resistance |
| Stirring Speed | 1520Rounds/Min |
| Highest Power | 1800W |
| Sample Installing Quantities | 4 pieces |
| Working Environment | Ambient temperature: 15--35ºC Ambient Humidity: <85% |
| Power Supply | 220V ac±10%50Hz±1Hz |
| Dimension(largest) | 220*190*500(L*W*H) |
| Weight | 12Kg |
