• Model NO.：TCTA
• Length of Furnace：500 ~ 600mm
• Display：LCD
• Color：White
• Auxiliary：Computers, Compressed Gases, Vacuum Cleaner
• Test Object：Wire and Cables
• Inner Diameter of Furnace：40 ~ 60mm
• Accuracy：0.1L,Min
• Temperature Control Method：Pid
• Dimension of Combustion Boat：45 ~ 100mm, Width 12 ~ 30mm, Depth 5 ~ 10mm
• Conducitivy Measuring Range：0.01us , mm ~ 100us , mm
• Language：English
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：30 Sets,Month

Basic Info.

Model NO. TCTA Length of Furnace 500 ~ 600mm Display LCD Color White Auxiliary Computers, Compressed Gases, Vacuum Cleaner Test Object Wire and Cables Inner Diameter of Furnace 40 ~ 60mm Accuracy 0.1L/Min Temperature Control Method Pid Dimension of Combustion Boat 45 ~ 100mm, Width 12 ~ 30mm, Depth 5 ~ 10mm Conducitivy Measuring Range 0.01us / mm ~ 100us / mm Language English Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 30 Sets/Month

Product Description

Introduction:

The International Electrotechnical Commission IEC 60754 Part 1 and Part 2 test is performed to determine the degree of acidity of gases evolved during the combustion of materials taken from electric cables by measuring the pH & conductivity.
IEC 60754-1 is halogen-free cable came from and including the polymer to halogenated compounds on the basis of the additive compounds emitted during combustion, except the fluoridation hydracids, it is measure for gas of halogen volume, IEC 60754-2 for electrical or optical cable from compounds emitted during the combustion of measure the gas of oxidation limit.

Standard:
· IEC 60754-1: Test on gases evolved during combustion of materials from cables-Part 1: Determination of the halogen acid gas content.
· IEC 60754-2: Test on gases evolved during combustion of materials from cables - Part 2: Determination of acidity (by pH measurement) and conductivity.

Feature

1. The gas emission tester is designed with optimized structure, logical layout, and easy to operated.
2. All the fixtures are made of stainless steel.
3.The effective length of the tube-type furnace is 500 ~ 600mm, inner diameter is 40 ~ 60mm, with adjustable electric systems.
4. Equipped with imported thermocouple from United States.
5. The size of the combustion boat is length 45 ~ 100mm, width 12 ~ 30mm, depth 5 ~ 10mm.
6. The electrical conductivity measuring range is 0.01uS / mm ~ 100uS / mm.
7. The control system using an electronic temperature control, intelligent control tube furnace temperature.
8. The halogen acid gas content test apparatus is equipped with two gas collection bottles.
9. The size of the sample chamber is 1 liter.
10. The apparatus is equipped with a PH value and conductivity detector, with an electronic display and an electrode.
11.Air flow meter is equipped with silicon dioxide fire pipeline to prevent corrosion by the gas.
12. Activated carbon (air filter): filter air through a filter.
13.The silicone is used for drying air source.
14.Pyrex pipeline: Users can easily insert sample into the Prius tube to protect the pipeline from damage.
15. Combustion boat moving system: combustion boat moves automatic to achieve more intelligent test.
16.The mode switching: mode switch (two test methods to choose from, IEC 60754-1 & IEC 60754-2).
17. The temperature alarm system: control the furnace temperature against overheating.
18. Timer: IEC 60754-1 or IEC 60754-2 time measurement device.
19. Drawer:used to store parts of the box (such as conductivity meters, pH meter, etc.)
20.Temperature indicator: shows the furnace core temperature.
21. Permanent magnetic stirrer: The agitator is used to stir the combustion gases in distilled water.
22.Conductivity meter:An instrument which used to measure the combustion gas conductivity.


Installation requirements

Power supply	AC 220V, 50/60Hz, 20A
Size	1,500 (W) x 500 (D) x 600 (H) mm
Weight	76KG
Accessories	Computers, compressed gases, vacuum cleaner

Factory overview

Customer Feedback

Germany

USA

Transporation

FAQ
1.What's the delivery time?
About 50 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
