5 Positions Existent Gum Content Test Equipment by ASTM D381

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：12 Months
  • Display：Digital
  • Appliance：Petrochemical
  • Portable：Non Portable
  • Certification：ISO9001

Base Info

  • Model NO.：EGT-II
  • Test Standard：ASTM D381
  • Test Method：Jet Evaporation
  • Power Supply：AC(220±10%)V,50Hz
  • Power Consumption：2500W
  • Dimension of Evaporation Bath：Φ260mm*130mm
  • Test Position：5
  • Dimension of Sample Positions：Φ51mm*70mm
  • Working Temperature：(160~165)ºC
  • Dimension：590*480*340mm3
  • Color：White
  • OEM Service：Available
  • Transport Package：Plywood Case
  • Specification：Small
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：50 Sets,Month

Description

Power supplyAC(220±10%)V,50Hz,2500WDimension of evaporation bathΦ260mm*130mmSample positions3 positionsDimension of sample positionsΦ51mm*70mmWorking temperature(160~165)ºCTemperature controlAutomaticTemperature displayDigital displayFlow displayDisplayed by a ball float type flowmeter.Working pressure of air reducing valve0.035MPaAir sourceExternal connection, over (1000±150)ml/sDimension590*480*340mm (Thermometer holder is not included)No.ItemUnitQty1Air compressorSet12Air compressor power supply line(Connected by air compressor specification requirements)Piece13Trumpet type nozzlePiece34Thermometer holderPiece35BeakerPiece66Thermometer (-5ºC~400ºC, scale division is ±1ºC)Piece4715 A fuse (Φ5×20)Piece28Air hosePiece19Sintered glass funnelPiece110Stainless steel forceps (25 cm)Piece111Crucible pliersPiece112Air filter assemblySet1  Factory overview5 Positions Existent Gum Content Test Equipment by ASTM D381
Customer Feedback

Germany
5 Positions Existent Gum Content Test Equipment by ASTM D381
USA
5 Positions Existent Gum Content Test Equipment by ASTM D381
Package
5 Positions Existent Gum Content Test Equipment by ASTM D381
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
