SA1000 Series Frequency Characteristic Analyzer with Big Screen
Shijiazhuang Suin Instruments Co., Ltd.- Warranty：18 Months
- OEM/ODM：Yes
- Sweep Range：20Hz~140MHz
- Sweep Mode：Linear, Log or Tone
- DC Offset：±4V
- Transport Package：Carton Package
Base Info
- Model NO.：SA1030C,D, SA1050C,D, SA1080C,D, SA1140C,D
- Specification：363*154*327 mm
- Trademark：SUIN
- Origin：China
- HS Code：9031809090
- Production Capacity：30, 000 Sets,Year
Description
SA1000C:amplitude-frequency,phase-frequency,frequency discrimination and SParameters can be measured
SA1000D:amplitude-frequency,phase-frequency and frequency discrimination can be measuredSweep Mode Linear,Log or Tone Output Amplitude >0.5Vrms Input Impedance 50Ω/High Impedance Output Impedance 50Ω Output Attenuation 0~80dB,1dB step Input Gain 10~-30dB,10dB step Phase Range -180°~+180° Phase Resolution 1° Amplitude range of input 0.1V≤A≤10V DC Offset ±4V General Characterisctics Display 7'' TFT LCD,800*480 Interface RS-232,USB Device Power AC220(1±10%)V,50(1±5%)Hz,<60VA Dimension&Weight 363*154*327 mm,Approx,4.8kgs
SA1000D:amplitude-frequency,phase-frequency and frequency discrimination can be measured
